Page 393: Dimensions

Appendix A
Hardware Reference
A–9
The following tables summarize the specifications and dimensions for the
MicroLogix 1000 HHP.
General Specifications
Description
Specification: 1761-HHP-B30
Operating Power
2.0W
Operating Temperature
0
°
C to +50
°
C (+32
°
F to +122
°
F)
Storage Temperature
–20
°
C to +60
°
C (–4
°
F to +140
°
F)
Operating Humidity
5 to 95% noncondensing
Vibration (Operating and
Non-operating)
10 to 500 Hz
0.762 mm (0.030 in.) peak to peak
1.5g maximum peak acceleration
1 hr in x, y, and z axis
Shock
Operating: 50g peak acceleration for 11
±
1 ms
duration 3 times in x, y, and z axis
Non-operating: 50g peak acceleration for 11
±
1 ms
duration 3 times in x, y, and z axis
Agency Certification
(when product or packaging is
marked)
•
C-UL Class 1, Division 2 Groups A, B, C, D
certified
•
UL listed (Class 1, Division 2 Groups A, B, C, D
certified)
•
CE marked for all applicable directives
Display Type
LCD 16 character x 2 line display
Keypad
rubber/carbon colored coded
Input Specifications
Description
Specification
Type
24V dc
Dimensions
Terminal: 1761-
Width:
mm (in.)
Height:
mm (in.)
Depth:
mm (in.)
HHP
95 (3.74)
170 (6.69)
35 (1.37)
Hand-Held Programmer
Specifications
