Chapter 11
Using Data Handling Instructions
11–13
instruction’s parameters, you must go into the overwrite mode. (See page
17–4.)
P 0 0 0 F L L S R C
N 1 1 0
P 0 0 0 F L L D E S T
# C 1 2 0 0 0 0 H
P 0 0 0 F L L L E N
5
The following general information applies to move and logical instructions.
Entering Parameters
•
Source is the address of the value on which the logical or move operation
is to be performed. It can be a word address or a constant. If the
instruction has two source operands, it will not accept constants in both
operands.
•
Destination is the address where the resulting data is stored. It must be a
word address.
Entering the Instructions
You enter the instructions from within the program monitor functional area.
The following items apply when entering the instructions:
•
Whenever you see asterisks on the display, the HHP is waiting for data
entry (i.e., a number).
•
You can return to previously entered operands by pressing this key:
Then if you want to edit that operand, press DEL or FUN-DEL and enter
new parameters. Press ENT to accept the operand and move on to the next
one. Once the entire instruction is entered, if you want to edit the
instruction’s parameters, you must go into the overwrite mode. (See page
17–4.)
5
ENT
ANB
0 1
FUN
To enter the function code, press:
Move and Logical Instructions
Overview
