Appendix C
Valid Addresssing Modes and File Types
for Instruction Parameters
C–8
Instruction
Valid Value
Ranges
Valid File Types
Valid Addressing
Mode(s)
Instruction
Parameter
Description
NEQ
Not Equal
source A
direct, indexed direct
O, I, S, B, T, C, R, N
Not Applicable
source B
immediate, direct,
indexed direct
O, I, S, B, T, C, R, N
–32,768–32,767
f-min–f-max
NOT
Logical NOT
source
direct, indexed direct
O, I, S, B, T, C, R, N
Not Applicable
destination
direct, indexed direct
O, I, S, B, T, C, R, N
Not Applicable
OR
Or (bit input)
source bit
direct
O, I, S, B, T, C, R, N
(bit level)
Not Applicable
OR
Or (word output)
source A
direct, indexed direct
O, I, S, B, T, C, R, N
–32,768–32,767
source B
direct, indexed direct
O, I, S, B, T, C, R, N
–32,768–32,767
destination
direct, indexed direct
O, I, S, B, T, C, R, N
Not Applicable
ORI
Or Inverted
source bit
direct
O, I, S, B, T, C, R, N
(bit level)
Not Applicable
OSR
One-Shot Rising
bit address
direct
O, I, S, B, T, C, R, N
Not Applicable
OUT
Output (or Output
Energize)
bit address
direct
O, I, S, B, T, C, R, N
Not Applicable
RAC
HSC Reset
Accumulator
counter
direct
C
Not Applicable
source
immediate, direct
O, I, S, B, T, C, R, N
–32,768–32,767
f-min–f-max
RES
Reset (timer/counter)
structure
direct
T, C, R
(element level)
Not Applicable
RES
Reset (high-speed
counter)
structure
direct
T, C, R
(element level)
Not Applicable
RET
Return
Not Applicable
RST
Reset (or Output
Unlatch)
bit address
direct
O, I, S, B, T, C, R, N
Not Applicable
RTO
Retentive Timer
timer
direct
T (element level)
Not Applicable
time base
immediate
0.01 or 1.00
preset
(contained in the
timer register)
0–32,767
accum
(contained in the
timer register)
0–32,767
SBR
Subroutine
Not Applicable
