After You’ve Entered Your Program
Chapter 18
18–25
Using Short Cut Keys
The following table shows the short cut keys you can press to go directly to
the file and rung you want to monitor.
To go to: Press the following key sequence:
a designated file and
rung (e.g., 5/3)
rung
number
ORB
+ - /
ENT file
number
MON
rung 0 of a designated
file (e.g., 10/0)
ORB
+ - /
ENT file
number
MON
a designated rung in
the current file (e.g., 4)
ENT rung
number
MON
Monitoring Data Table Files
The data table files contain information used in your program. By
monitoring the data table files, you can watch how the data changes as your
program runs. Data table files that you can monitor include:
•
Output (O)
•
Input (I)
•
Status (S)
•
Bit (B)
•
Timer (T)
•
Counter (C)
•
Control (R)
•
Integer (N)
See page 18–27 for example displays of each data table file.
To monitor a data element used as an instruction parameter, begin at the
program monitor display.
1. Arrow to the instruction parameter you want to monitor.
2. Access the data monitor to view the data table for the current instruction.
MON ENT
