Appendix B
Programming Reference
B–19
Mnemonic
False Execution Time
(approx.
µ
seconds)
True Execution Time
(approx.
µ
seconds)
Memory Usage
(user words)
Name Instruction Type
RET 3.16 31.11 0.50 Return from Subroutine Program Flow Control
RST 3.16 4.97 0.75 Reset Basic
RTO 27.49 38.34 1.00 Retentive Timer Basic
SBR LD SBR 0.99 1.45 0.50 Subroutine Program Flow Control
SCL 6.78 169.18 1.75 Scale Data Math
SET 3.16 4.97 0.75 Set Basic
SQC 27.40 60.52 2.00 Sequencer Compare Application Specific
SQL 28.12 53.41 2.00 Sequencer Load Application Specific
SQO 27.40 60.52 2.00 Sequencer Output Application Specific
SQR 6.78 71.25 1.25 Square Root Math
STD 3.16 6.69 0.50
Selectable Timer
Interrupt Disable
Application Specific
STE 3.16 10.13 0.50
Selectable Timer
Interrupt Enable
Application Specific
STS 6.78 24.59 1.25
Selectable Timer
Interrupt Start
Application Specific
SUB 6.78 33.52 1.50 Subtract Math
SUS 7.87 10.85 1.50 Suspend Program Flow Control
TND 3.16 7.78 0.50 Temporary End Program Flow Control
TOD 6.78 49.64 1.00 Convert to BCD Data Handling
TOF 31.65 39.42 1.00 Timer Off-Delay Basic
TON 30.38 38.34 1.00 Timer On-Delay Basic
XOR 6.92 33.64 1.50 Exclusive Or Data Handling
