Appendix C
Valid Addressing Modes and File Types
for Instruction Parameters
C–3
Instruction
Description
Instruction
Parameters
Valid Addressing
Mode(s)
Valid File Types
Valid Value
Ranges
ADD
Add
source A
immediate, direct,
indexed direct
O, I, S, B, T, C, R, N
–32,768–32,767
f-min–f-max
source B
immediate, direct,
indexed direct
O, I, S, B, T, C, R, N
–32,768–32,767
f-min–f-max
destination
direct, indexed direct
O, I, S, B, T, C, R, N
Not Applicable
AND
And (bit input)
source bit
direct
O, I, S, B, T, C, R, N
(bit level)
Not Applicable
AND
And (word output)
source A
immediate, direct,
indexed direct
O, I, S, B, T, C, R, N
–32,768–32,767
source B
immediate, direct,
indexed direct
O, I, S, B, T, C, R, N
–32,768–32,767
destination
direct, indexed direct
O, I, S, B, T, C, R, N
Not Applicable
ANI
And Inverted
source bit
direct
O, I, S, B, T, C, R, N
(bit level)
Not Applicable
BSL
Bit Shift Left
file
indexed direct
O, I, S, B, N
Not Applicable
control
direct
R (element level)
Not Applicable
bit address
direct
O, I, S, B, T, C, R, N
(bit level)
Not Applicable
length
(contained in the
control register)
0–2048
BSR
Bit Shift Right
file
indexed direct
O, I, S, B, N
Not Applicable
control
direct
R (element level)
Not Applicable
bit address
direct
O, I, S, B, T, C, R, N
(bit level)
Not Applicable
length
(contained in the
control register)
0–2048
CLR
Clear
destination
direct, indexed direct
O, I, S, B, T, C, R, N
Not Applicable
COP
Copy File
source
indexed direct
O, I, S, B, T, C, R, N
Not Applicable
destination
indexed direct
O, I, S, B, T, C, R, N
Not Applicable
length
immediate
1–128; 1–42
when destination
is T,C,R
CTD
Count Down
counter
direct
C (element level)
Not Applicable
preset
(contained in the
counter register)
–32,768–32,767
accum
(contained in the
counter register)
–32,768–32,767
