A Appendix
A–1
Hardware Reference
This appendix lists the MicroLogix 1000 Programmable Controller and
MicroLogix 1000 HHP:
•
specifications
•
dimensions
•
accessories and replacement parts
For AIC+ specifications, see the Advanced Interface Converter User Manual,
Publication 1761-6.4. For DNI specifications, see the DeviceNet Interface
t
User Manual, Publication 1761-6.5.
Controller Types
Catalog Number Description
1761-L16AWA 10 pt. ac input, 6 pt. relay output, ac power supply controller
1761-L32AWA 20 pt. ac input, 12 pt. relay output, ac power supply controller
1761-L20AWA-5A
12 pt. ac input, 4 pt. analog input, 8 pt. relay output, 1 pt. analog output, ac
power supply controller
1761-L10BWA 6 pt. dc input, 4 pt. relay output, ac power supply controller
1761-L16BWA 10 pt. dc input, 6 pt. relay output, ac power supply controller
1761-L20BWA-5A
12 pt. dc input, 4 pt. analog input, 8 pt. relay output, 1 pt. analog output, ac
power supply controller
1761-L32BWA 20 pt. dc input, 12 pt. relay output, ac power supply controller
1761-L10BWB 6 pt. dc input, 4 pt. relay output, dc power supply controller
1761-L16BWB 10 pt. dc input, 6 pt. relay output, dc power supply controller
1761-L20BWB-5A
12 pt. dc input, 4 pt. analog input, 8 pt. relay output, 1 pt. analog output, dc
power supply controller
1761-L32BWB 20 pt. dc input, 12 pt. relay output, dc power supply controller
1761-L16BBB 10 pt. dc input, 4 pt. FET and 2 pt. relay outputs, dc power supply controller
1761-L32BBB 20 pt. dc input, 10 pt. FET and 2 pt. relay outputs, dc power supply controller
1761-L32AAA 20 pt. ac input, 10 pt. triac and 2 pt. relay outputs, ac power supply controller
Controller Specifications
