General Output Specifications
Type
Relay
MOSFET
Triac
Voltage
See Wiring Diagrams, p.
2–6.
Maximum
Load
Current
Refer to the
Relay Contact
Rating Table.
1.0A per point @ 55
°
C (131
°
F)
1.5A per point @ 30
°
C (86
°
F)
0.5A per point @ 55
°
C (131
°
F)
1.0A per point @ 30
°
C (86
°
F)
Minimum
Load
Current
10.0 mA
1 mA
10.0 mA
Current
per
Controller
1440 VA
3A for L16BBB
6A for L32BBB
1440 VA
Current
per
Common
8.0A
3A for L16BBB
6A for L32BBB
Not Applicable
Maximum
Off State
Leakage
Current
0 mA
1 mA
2 mA @ 132V ac
4.5 mA @ 264V ac
Off to On
Response
10 ms max.
0.1 ms
8.8 ms @ 60 Hz
10.6 ms @ 50 Hz
On to Off
Response
10 ms max.
1 ms
11.0 ms
Surge
Current
per Point
Not Applicable
4A for 10 ms
➀
10A for 25 ms
➀
➀
Repeatability is once every 2 seconds at 55
°
C (131
°
F).
Relay Contact Rating Table (applies to all Bulletin 1761 controllers)
Maximum Volt
Amperes
mp r
Continuou
Voltamperes
Maximum Volts
Make
Break
Amperes Continuous
Make
Break
240V ac
7.5A
0.75A
2.5A
1800 VA
180 VA
120V ac
15A
1.5A
125V dc
0.22A
➀
1.0A
28 VA
24V dc
1.2A
➀
2.0A
28 VA
➀
For dc voltage applications, the make/break ampere rating for relay contacts can be determined
by dividing 28 VA by the applied dc voltage. For example, 28 VA
÷
48V dc = 0.58A. For dc
voltage applications less than 48V, the make/break ratings for relay contacts cannot exceed 2A.
For dc voltage applications greater than 48V, the make/break ratings for relay contacts cannot
exceed 1A.
