Appendix B
Programming Reference
B–13
The table below provides the function codes for each instruction. The
instructions are listed in alphabetical order.
Mnemonic
HHP
Display
Function
Code
Name Instruction Type
ADD ➀ 80 Add Math
ANB ➀ 13 And Block Basic
AND (bit input) 22 And Basic
AND (word output) ➀ 108 And Data Handling
ANI 23 And Inverted Basic
BSL ➀ 150 Bit Shift Left Application Specific
BSR ➀ 151 Bit Shift Right Application Specific
CLR ➀ 85 Clear Math
COP ➀ 104 File Copy Data Handling
CTD ➀ 6 Count Down Basic
CTU ➀ 5 Count Up Basic
DCD ➀ 102 Decode 4 to 1 of 16 Data Handling
DDV ➀ 84 Double Divide Math
DIV ➀ 83 Divide Math
ENC ➀ 103 Encode 1 of 16 to 4 Data Handling
AND EQU EQU 51
EQU LD EQU EQU 50 Equal Comparison
OR EQU
EQU
52
FFL ➀ 113 FIFO Load Data Handling
FFU ➀ 114 FIFO Unload Data Handling
FLL ➀ 105 Fill File Data Handling
FRD ➀ 101 Convert from BCD Data Handling
AND GEQ GEQ 66
GEQ LD GEQ
GEQ
65 Greater Than or Equal Comparison
OR GEQ
GEQ
67
AND GRT
GRT
63
GRT LD GRT GRT 62 Greater Than Comparison
OR GRT
GRT
64
HSC ➀ 170 High-Speed Counter High-Speed Counter
HSD ➀ 174
High-Speed Counter
Interrupt Disable
High-Speed Counter
HSE ➀ 173
High-Speed Counter
Interrupt Enable
High-Speed Counter
➀ Multiple displays.
Function Codes
