Appendix B
Programming Reference
B–14
Mnemonic
HHP
Display
Function
Code
Name Instruction Type
HSL ➀ 171
High-Speed Counter
Load
High-Speed Counter
IIM ➀ 138
Immediate Input with
Mask
Program Flow Control
INT LD INT INT 158 Interrupt Subroutine Application Specific
IOM ➀ 139
Immediate Output with
Mask
Program Flow Control
JMP ➀ 130 Jump to Label Program Flow Control
JSR ➀ 132 Jump to Subroutine Program Flow Control
LBL LD LBL LBL 131 Label Program Flow Control
LD 20 Load Basic
LDI 21 Load Inverted Basic
LDT
LDT
26 Load True Basic
AND LEQ
LEQ
60
LEQ LD LEQ
LEQ
59 Less Than or Equal Comparison
OR LEQ
LEQ
61
AND LES
LES
57
LES LD LES LES 56 Less Than Comparison
OR LES
LES
58
LFL ➀ 115 LIFO Load Data Handling
LFU ➀ 116 LIFO Unload Data Handling
AND LIM LIM 72
LIM LD LIM LIM 71 Limit Test Comparison
OR LIM
LIM
73
MCR ➀ 135 Master Control Reset Program Flow Control
AND MEQ MEQ 69
Mas e aris f r
MEQ LD MEQ MEQ 68
Masked Comparison for
Equal
Comparison
OR MEQ
MEQ
70
Equal
MOV ➀ 106 Move Data Handling
MPP ➀ 12 Memory Pop Basic
MPS ➀ 10 Memory Push Basic
MRD ➀ 11 Memory Read Basic
MSG ➀ 200 Message Communication
MUL ➀ 82 Multiply Math
MVM ➀ 107 Masked Move Data Handling
➀ Multiple displays.
