Programming 7–5
Metering
This group of parameters consists of commonly viewed drive operating conditions such as
motor speed, drive output voltage, current and command frequency. All parameters in this
group are Read Only and can only be viewed.
[Output Current]
This parameter displays the output current present at
terminals U, V & W (T1, T2 & T3).
Parameter Number 54
Parameter Type Read Only
Display Units / Drive Units 0.1 Amp / 4096 = 100% Drive Rated Amps
Factory Default None
Minimum Value 0.0
Maximum Value 200% Rated Drive Output Current
[Output Voltage]
This parameter displays the commanded output voltage at
terminals U, V & W (T1, T2 & T3).
Parameter Number 1
Parameter Type Read Only
Display Units / Drive Units 1 Volt / 4096 = 100% Drive Rated Volts
Factory Default None
Minimum Value 0
Maximum Value 200% Rated Drive Output Voltage
[Output Power]
This parameter displays the output power present at
terminals U, V & W (T1, T2 & T3).
Parameter Number 23
Parameter Type Read Only
Display Units / Drive Units 1 kilowatt / 4096 = 100% Drive Rated kW
Factory Default None
Minimum Value –200% Rated Drive Output Power
Maximum Value +200% Rated Drive Output Power
[DC Bus Voltage]
This parameter displays the DC bus voltage level.
Parameter Number 53
Parameter Type Read Only
Display Units / Drive Units 1 Volt / 4096 = 100% Drive Rated Volts
Factory Default None
Minimum Value 0
Maximum Value 200% DC Bus Voltage Max
[Output Freq]
This parameter displays the output frequency present at
terminals U, V & W (T1, T2 & T3).
Parameter Number 66
Parameter Type Read Only
Display Units / Drive Units 0.01 Hertz / 32767 = Maximum Freq Forward
Factory Default None
Minimum Value –400.00 Hz
Maximum Value +400.00 Hz
[Freq Command]
This parameter displays the frequency that the drive is
commanded to output. This command may come from any
one of the frequency sources selected by [Freq Select 1]
or [Freq Select 2].
Parameter Number 65
Parameter Type Read Only
Display Units / Drive Units 0.01 Hertz / 32767 = Maximum Freq Forward
Factory Default None
Minimum Value –400.00 Hz
Maximum Value +400.00 Hz
[Anlg In 0 Freq] – Stand-Alone Version Only
[Anlg In 1 Freq]
– Stand-Alone Version Only
[Anlg In 2 Freq]
– Stand-Alone Version Only
These parameters displays the frequency command
present at the specified analog input terminals. This value
is displayed whether or not this is the active frequency
command.
Parameter Number 138-140
Parameter Type Read Only
Display Units / Drive Units 0.01 Hertz / 32767 = Maximum Freq
Factory Default None
Minimum Value 0.00 Hz
Maximum Value 400.00 Hz
