Chapter
7
Programming
Chapter 7 describes the 1336 SPIDER parameters . The parameters are
divided into groups for ease of programming and operator access.
Grouping replaces a sequentially numbered parameter list with
functional parameter groups that increases operator efficiency and
helps to reduce programming time. For most applications, this means
simplicity at startup with minimum drive tuning.
Function Index The Function Index shown below provides a directory of the
parameters required for each drive function. The Page Number
locates within a group all parameters associated with that specific
function.
Function Page Number
Analog Input Config 7–30
At Temperature 7–28
Auto Restart 7–20
Bus Regulation 7–40
Custom Volts-per-Hertz 7–56
DC Brake-to-Stop 7–13
DC Hold Brake 7–13
Dwell 7–19
Economize 7–56
Electronic Shear Pin 7–32
Encoder Feedback 7–49
Fault Buffer History 7–32
Frequency Select 7–16
Inertia Ride-Thru 7–25
I/O Configuration 7–27
Last Speed 7–16
Line Loss Detect 7–22
Line Loss Recovery 7–22
Load Loss Detect 7–26
Minimum/Maximum Frequency 7–9
Overload Protection 7–11
Power Loss Ride-Thru 7–23
Preset Frequencies 7–16
Process Control 7–52
Process Display 7–48
Remote I/O 7–47
S-Curve Acceleration 7–21
Skip Frequencies 7–17
Slip Compensation 7–20
Step Logic 7–60
Stop Modes 7–9
Synchronized Speed Change 7–12
Traverse Function 7–24
Programming Flow Chart The flow chart provided on pages 7-2 and 7-3 highlight the steps
required to access each group of parameters and lists all parameters
for each group.
