Page 147: Appendix, Protection, Environment
Appendix
A
Specifications and
Supplemental Information
Appendix A provides specifications and supplemental information
including a parameter cross reference and derate information.
Specifications
Protection
200-240V Drive
380-480V Drive
AC Input Overvoltage Trip:
285V AC
570V AC
AC Input Undervoltage Trip:
120V AC
240V AC
Bus Overvoltage Trip:
405V DC
810V DC
Bus Undervoltage Trip:
160V DC
320V DC
Nominal Bus Voltage:
324V DC
648V DC
Heat Sink Thermostat
Monitored by microprocessor overtemp trip.
Drive Overcurrent Trip
Software Current Limit:
20 to 240% of [Rated Amps].
Hardware Current Limit:
125 to 270% of [Rated Amps].
Instantaneous Current Limit: 135 to 290% of [Rated Amps].
Line transients:
Impulse with standard voltage (1.2/50
µ
s):4000 volts per EN 50178.
Power Ride-Thru:
30 milliseconds at full load.
Logic Control Ride-Thru:
0.5 seconds minimum, 2 seconds typical.
Ground Fault Trip:
Phase-to-ground on drive output.
Short Circuit Trip:
Phase-to-phase on drive output.
Environment
Altitude:
1000 m (3300 ft) max. without derating.
Ambient Operating Temperature
IP20, NEMA Open Type:
0 to 50 degrees C (32 to 122 degrees F).
Storage Temperature:
–40 to 70 degrees C (–40 to 158 degrees F).
Atmosphere
Important: Drive must not be installed in an area where
the ambient atmosphere contains volatile or corrosive
gas, vapors or dust. If the drive is not going to be installed
for a period of time, it must be stored in an area where it
will not be exposed to a corrosive atmosphere.
Relative Humidity:
5 to 95% non-condensing, 75% average.
Shock:
15G peak for 11ms duration (
±
1.0ms).
Vibration:
1G continuous.
Agency Certification:
1
Note: Installation guidelines called out in Appendix C must be adhered to.
U.L. Listed
CSA Certified
Marked for all applicable directives
1
Product Standards EN 61800-3
Emissions
EN 50081-1
EN 50081-2
EN 55011 Class A
EN 55011 Class B
Immunity
EN 50082-1
EN 50082-2
IEC 801-1, 2, 3, 4, 6, 8 per EN 50082-1, 2
Low Voltage
EN 60204-1
EN 50178
