Programming 7–39
Diagnostics
[Power Mode]
This parameter displays the power mode.
Parameter Number 142
Parameter Type Read Only
Factory Default None
Units Display Drive
“1” 1 Power up sequence in progress
“2” 2 Precharge in progress
“3” 3 Bus voltage being stored in memory
“4” 4 Ready for run command after
power up
“5” 5 Power stage diagnostics running
“6” 6 Line loss detection occurred
“7” 7 Ready for run command after stop
“8” 8 Drive running
“9” 9 Motor flux decay delay
“10” 10 DC braking in progress
“11” 11 Drive fault occurred
“12” 12 Flying start search enabled
“13” 13 Deceleration in progress
“14” 14 SCR wake mode
“15” 15 SCR check mode
“16” 16 SCR wait mode
[Output Pulses]
This parameter displays the number of output cycles for
the PWM waveform. The count rolls over at 65535.
Parameter Number 67
Parameter Type Read Only
Display Units / Drive Units 1 Pulse / Pulses
Factory Default None
Minimum Value 0
Maximum Value 65535
[Current Angle]
This parameter displays the angle, in degrees, of
displacement between output voltage and output current.
The cosine of this number is an approximation of output
power factor.
Parameter Number 72
Parameter Type Read Only
Display Units / Drive Units 1 Deg / 255 = 360 Deg
Factory Default None
[Heatsink Temp]
This parameter displays the heatsink temperature of the
drive.
Parameter Number 70
Parameter Type Read Only
Display Units / Drive Units 1 ° C / Deg. C
Factory Default None
Minimum Value 0
Maximum Value 255 ° C
[Set Defaults]
Setting this parameter to “Defaults Init” resets all
parameters to their factory values.
Parameter Number 64
Parameter Type Read and Write
Factory Default “Ready”
Units Display Drive
“Ready” 0 Display after function complete.
“Store to EE” 1
“Rcll frm EE” 2
“Default Init” 3 Resets all parameters to factory
settings.
