Human Interface Module 5–13
Handheld HIM Operation If remote programming is desired, a handheld HIM can be connected
to the drive. Refer to Adapter Definitions in Chapter 2 for details.
Important: Disconnecting a HIM (or other SCANport device) from a
drive while power is applied will cause a “Serial Fault,”
unless the [Logic Mask] parameter has been set to disable
this fault or Control Logic (Control Status menu) has been
disabled (except Series A HIMs below version 3.0). Setting
Bit 1 of the [Logic Mask] parameter to “0” will disable
“Serial Fault” from a HIM on port 1. Note that this also
disables all HIM control functions except Stop.
Password Mode (continued)
Press these keys . . . while following these steps . . . The HIM Display will show . . .
Login to Drive 2. The Program/EEProm modes and the Control Logic/Clear Queue
menus are now password protected and will not appear in the menu.
To access these modes, perform the following steps.
A. Press the Increment (or Decrement) key until “Password” is
displayed.
B. Press Enter. “Login” will be displayed.
C. Press Enter, “Enter Password” will be displayed.
D. Press the Increment (or Decrement) key until your correct password
is displayed. The SELect key will move the cursor (except Series A
HIMs below version 3.0).
E. Press Enter.
F. The Program and EEProm modes will now be accessible. To pre-
vent future access to program changes, logout as described below.
Choose Mode
Password
Password
Login
Enter Password
< 0>
Enter Password
< 123>
Choose Mode
Password
Logout from Drive 3. To prevent unauthorized changes to parameters, Logout must be per-
formed as described below.
A. Press the Increment (or Decrement) key until “Password” is
displayed.
B. Press Enter.
C. Press the Increment (or Decrement) key until “Logout” is displayed.
D. Press Enter to log out of the Password mode.
Choose Mode
Password
Password
Login
Password
Logout
Choose Mode
Password
or
or
or
or
