7–42 Programming
Masks
This group of parameters contains binary masks for all control functions. The masks control
which adapters can issue control commands.
Each mask contains a bit for each adapter. Individual bits
can be set to “Zero” to lockout control by an adapter or set
to “1” to permit an adapter to have control.
A Status description (bit ENUM) is displayed on line 1
(except Series A HIMs below version 3.0).
[Direction Mask]
This parameter controls which adapters can issue forward/
reverse commands.
If [Freq Select 1] or [Freq Select 2] is set to “Analog In 0”
and an Analog Option Board with bipolar input (LA6, LA7)
is installed, that input (designated “Analog In 0”) will have
exclusive ownership of direction. Bit 7 of [Direction Mask]
must not be set to “0” and no other device can have claimed
ownership of direction (i.e. TB5 - Run Reverse). If either
condition is true, a fault will be issued.
Parameter Number 94
Parameter Type Read and Write
Factory Default 01111110
Units Display Drive
“0” 0 Deny Control
“1” 1 Permit Control
[Start Mask]
This parameter controls which adapters can issue start
commands.
Parameter Number 95
Parameter Type Read and Write
Factory Default 01111111
Units Display Drive
“0” 0 Deny Control
“1” 1 Permit Control
[Jog Mask]
This parameter controls which adapters can issue jog
commands.
Parameter Number 96
Parameter Type Read and Write
Factory Default 01111111
Units Display Drive
“0” 0 Deny Control
“1” 1 Permit Control
[Reference Mask]
This parameter controls which adapters can select an
alternate reference; [Frequency Sel 1], [Frequency Sel 2]
or preset speeds.
Parameter Number 97
Parameter Type Read and Write
Factory Default 01111111
Units Display Drive
“0” 0 Deny Control
“1” 1 Permit Control
[Accel Mask]
This parameter controls which adapters can select [Accel
Time 1] and [Accel Time 2].
Parameter Number 98
Parameter Type Read and Write
Factory Default 01111111
Units Display Drive
“0” 0 Deny Control
“1” 1 Permit Control
TB4-TB6
Adapter 1
Adapter 2
Adapter 3
Adapter 4
Adapter 5
Adapter 6
LAx
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Mask
