Specifications and Supplemental Information A–11
Read/Write Parameter Record When using a compatible HIM (see Table 5.A), the parameters listed
can be uploaded to the HIM for downloading to other drives.
No. Name Setting No. Name Setting No. Name Setting No. Name Setting
5 Freq Select 1 ______
6 Freq Select 2 ______
7 Accel Time 1 ______
8 Decel Time 1 ______
9 Control Select ______
10 Stop Select 1 ______
11 Bus Limit En ______
12 DC Hold Time ______
13 DC Hold Level ______
14 Run On Power Up ______
15 Reset/Run Time ______
16 Minimum Freq ______
17 Base Frequency ______
18 Base Voltage ______
19 Maximum Freq ______
20 Maximum Voltage ______
22 MOP Increment ______
24 Jog Frequency ______
25 Anlg Out 0 Sel ______
27 Preset Freq 1 ______
28 Preset Freq 2 ______
29 Preset Freq 3 ______
30 Accel Time 2 ______
31 Decel Time 2 ______
32 Skip Freq 1 ______
33 Skip Freq 2 ______
34 Skip Freq 3 ______
35 Skip Freq Band ______
36 Current Limit ______
37 Overload Mode ______
38 Overload Amps ______
39 Flt Clear Mode ______
40 Line Loss Fault ______
41 Motor Type ______
42 Slip @ F.L.A. ______
43 Dwell Frequency ______
44 Dwell Time ______
45 PWM Frequency ______
47 Language ______
48 Start Boost ______
49 Break Frequency ______
50 Break Voltage ______
52 Stop Select 2 ______
56 S Curve Time ______
57 S Curve Enable ______
58 Common Bus ______
73 Preset Freq 4 ______
74 Preset Freq 5 ______
75 Preset Freq 6 ______
76 Preset Freq 7 ______
77 Speed Control ______
78 Traverse Inc _____
79 Max Traverse ______
80 P Jump ______
82 Cur Lim Trip En ______
83 Run Boost ______
85 Reset/Run Tries ______
90 Analog Trim En ______
91 Low Bus Fault ______
92 Logic Mask ______
93 Local Mask ______
94 Direction Mask ______
95 Start Mask ______
96 Jog Mask ______
97 Reference Mask ______
98 Accel Mask ______
99 Decel Mask ______
100 Fault Mask ______
101 MOP Mask ______
111 Data In A1 ______
112 Data In A2 ______
113 Data In B1 ______
114 Data In B2 ______
115 Data In C1 ______
116 Data In C2 ______
117 Data In D1 ______
118 Data In D2 ______
119 Data Out A1 ______
120 Data Out A2 ______
121 Data Out B1 ______
122 Data Out B2 ______
123 Data Out C1 ______
124 Data Out C2 ______
125 Data Out D1 ______
126 Data Out D2 ______
127 Process 1 Par ______
128 Process 1 Scale ______
129 Process 1 Txt 1 ______
130 Process 1 Txt 2 ______
131 Process 1 Txt 3 ______
132 Process 1 Txt 4 ______
133 Process 1 Txt 5 ______
134 Process 1 Txt 6 ______
135 Process 1 Txt 7 ______
136 Process 1 Txt 8 ______
150 4-20mA Loss Sel ______
154 Anlg Out 0 Offst ______
155 Flying Start En ______
156 FStart Forward ______
157 FStart Reverse ______
158 CR1 Out Select ______
159 Dig Out Freq ______
160 Dig Out Current ______
161 Dig Out Torque ______
169 Boost Slope ______
170 Rated Amps ______
171 Rated kW ______
172 EEPROM Cksum ______
173 Fault Alarms 1 ______
174 CR2 Out Select ______
175 CR3 Out Select ______
176 CR4 Out Select ______
177 Motor NP RPM ______
178 Motor NP Hertz ______
180 Process 2 Par ______
181 Process 2 Scale ______
182 Process 2 Txt 1 ______
183 Process 2 Txt 2 ______
184 Process 2 Txt 3 ______
185 Process 2 Txt 4 ______
186 Process 2 Txt 5 ______
187 Process 2 Txt 6 ______
188 Process 2 Txt 7 ______
189 Process 2 Txt 8 ______
190 Motor NP Volts ______
191 Motor NP Amps ______
192 Flux Amps Ref ______
193 KP Amps ______
194 IR Drop Volts ______
195 Slip Comp Gain ______
200 Flux Up Time ______
201 Motor OL Fault ______
204 Ground Warning ______
206 Alarm Mask 1 ______
213 PI Config ______
215 PI Ref Select ______
216 PI Fdbk Select ______
221 KI Process ______
222 KP Process ______
223 PI Neg Limit ______
224 PI Pos Limit ______
225 PI Preload ______
226 Shear Pin Fault ______
227 Adaptive I Lim ______
228 LLoss Restart ______
229 Freq Ref SqRoot ______
230 Save MOP Ref ______
231 Hold Level Sel ______
232 Current Lmt Sel ______
233 Anlg Out 0 Abs ______
234 Anlg Out 0 Lo ______
235 Anlg Out 0 Hi _____
237 Anlg In 0 Lo _____
238 Anlg In 0 Hi _____
239 Anlg In 1 Lo _____
240 Anlg In 1 Hi _____
241 Input Mode ______
242 TB3 Term 22 Sel ______
243 TB3 Term 23 Sel ______
244 TB3 Term 24 Sel ______
245 TB3 Term 26 Sel ______
246 TB3 Term 27 Sel ______
247 TB3 Term 28 Sel ______
248 Anlg In 2 Lo ______
249 Anlg In 2 Hi ______
250 Anlg Signal Loss ______
256 Line Loss Mode ______
264 Pulse In Scale ______
267 Dig At Temp ______
268 Motor Therm Flt ______
271 Alarm Mask 2 ______
274 Anlg Out 1 Sel ______
275 Anlg Out 1 Lo ______
276 Anlg Out 1 Hi ______
277 Anlg Out 1 Abs ______
278 Anlg Out 1 Offst ______
280 Pulse Out Select ______
281 Pulse Out Scale ______
288 Bus Regulation ______
289 Phase Loss Det ______
290 Load Loss Detect ______
291 Load Loss Level ______
292 Load Loss Time ______
303 Current Lmt En ______
304 Traverse Dec ______
305 Traverse Mask ______
307 Sync Time ______
308 Sync Mask ______
310 Sync Loss Sel ______
311 Sync Loss Gain ______
312 Sync Loss Time ______
313 Sync Loss Comp ______
315 Alt Type 2 Cmd ______
317 Run/Accel Volts ______
319 Speed Brake En ______
320 Line Loss Volts ______
321 Loss Recover ______
322 Ride Thru Volts ______
323 Min Bus Volts ______
324 Stability Gain ______
325 Bus Reg/Max Bus ______
326 Remote CR Output ______
327 At Time ______
329 Bidir In Offset ______
330 Phase Loss Mode ______
331 Phase Loss Level ______
332 Precharge Fault ______
