A–4 Specifications and Supplemental Information
Parameter Cross Reference - By Number
No. Name Group No. Name Group No. Name Group
1 Output Voltage Metering
2 % Output Curr Metering
3 % Output Power Metering
4 Last Fault Metering
5 Freq Select 1 Frequency Set + Setup
6 Freq Select 2 Frequency Set
7 Accel Time 1 Setup
8 Decel Time 1 Setup
9 Control Select Motor Control
10 Stop Select 1 Advanced Setup + Setup
11 Bus Limit En Advanced Setup
12 DC Hold Time Advanced Setup
13 DC Hold Level Advanced Setup
14 Run On Power Up Feature Select
15 Reset/Run Time Feature Select
16 Minimum Freq Advanced Setup + Setup
17 Base Frequency Motor Control
18 Base Voltage Motor Control
19 Maximum Freq Advanced Setup + Setup
20 Maximum Voltage Motor Control
22 MOP Increment Frequency Set
23 Output Power Metering
24 Jog Frequency Frequency Set
25 Anlg Out 0 Sel Analog I/O
26 Stop Mode Used Diagnostics
27-29 Preset Freq 1-3 Frequency Set
30 Accel Time 2 Advanced Setup
31 Decel Time 2 Advanced Setup
32-34 Skip Freq 1-3 Frequency Set
35 Skip Freq Band Frequency Set
36 Current Limit Setup
37 Overload Mode Setup
38 Overload Amps Setup
39 Flt Clear Mode Faults
40 Line Loss Fault Faults
41 Motor Type Advanced Setup
42 Slip @ F.L.A. Feature Select
43 Dwell Frequency Feature Select
44 Dwell Time Feature Select
45 PWM Frequency Advanced Setup
46 Encoder PPR Freq. Set + Enc. Fdbk.
47 Language Feature Select
48 Start Boost Motor Control
49 Break Frequency Motor Control
50 Break Voltage Motor Control
51 Clear Fault Faults
52 Stop Select 2 Advanced Setup
53 DC Bus Voltage Metering
54 Output Current Metering
55 Input Status Digital I/O + Diagnostics
56 S Curve Time Feature Select
57 S Curve Enable Feature Select
58 Common Bus Advanced Setup
59 Drive Status 1 Diagnostics
60 Drive Alarm 1 Diagnostics
61 Drive Type Ratings
62 Freq Source Diagnostics
63 Encoder Freq Metering + Enc. Fdbk.
64 Set Defaults Diagnostics
65 Freq Command Metering + Diagnostics
66 Output Freq Metering
67 Output Pulses Diagnostics
69 Drive Direction Diagnostics
70 Heatsink Temp Metering + Diagnostics
71 Firmware Ver. Ratings
72 Current Angle Diagnostics
73-76 Preset Freq 4-7 Frequency Set
77 Speed Control Feature Select + Process
PI + Encoder Feedback.
78 Traverse Inc Feature Select
79 Max Traverse Feature Select
80 P Jump Feature Select
81 Blwn Fuse Flt Faults
82 Cur Lim Trip En Faults
83 Run Boost Motor Control
84 Power OL Count Metering
85 Reset/Run Tries Feature Select
86-89 Fault Buffer 0-3 Faults
90 Analog Trim En Analog I/O
91 Low Bus Fault Faults
92 Logic Mask Masks
93 Local Mask Masks
94 Direction Mask Masks
95 Start Mask Masks
96 Jog Mask Masks
97 Reference Mask Masks
98 Accel Mask Masks
99 Decel Mask Masks
100 Fault Mask Masks
101 MOP Mask Masks
102 Stop Owner Owners
103 Direction Owner Owners
104 Start Owner Owners
105 Jog Owner Owners
106 Reference Owner Owners
107 Accel Owner Owners
108 Decel Owner Owners
109 Fault Owner Owners
110 MOP Owner Owners
111 -118 Data In A1-D2 Adapter I/O
119 -126 Data Out A1-D2 Adapter I/O
127 Process 1 Par Process Display
128 Process 1 Scale Process Display
129-136 Process 1 Txt 1-8 Process Display
137 MOP Freq Metering
138-140 Anlg In 0-2 Freq Metering
141 Motor Mode Diagnostics
142 Power Mode Diagnostics
143 Flt Motor Mode Faults
144 Flt Power Mode Faults
145 Fault Frequency Faults
146 Fault Status 1 Faults
147 Rated Volts Ratings
148 Rated CT Amps Ratings
149 Rated CT kW Ratings
150 4-20mA Loss Sel Analog I/O
151 Maximum Speed Encoder Feedback
152 Encoder Type Encoder Feedback
153 Motor Poles Encoder Feedback
154 Anlg Out 0 Offst Analog I/O
155 Flying Start En Feature Select
156 FStart Forward Feature Select
157 FStart Reverse Feature Select
158 CR1 Out Select Digital I/O
159 Dig Out Freq Digital I/O
160 Dig Out Current Digital I/O
161 Dig Out Torque Digital I/O
162 Torque Current Metering
163 Flux Current Metering
164 Speed KP Encoder Feedback
165 Speed KI Encoder Feedback
166 Speed Error Encoder Feedback
167 Speed Integral Encoder Feedback
168 Speed Adder Encoder Feedback
169 Boost Slope Motor Control
170 Rated Amps Ratings
171 Rated kW Ratings
172 EEPROM Cksum Diagnostics
173 Fault Alarms 1 Faults
174-176 CR2-4 Out Select Digital I/O
177 Motor NP RPM Setup + Enc. Fdbk.
178 Motor NP Hertz Setup + Enc. Fdbk.
179 Local Owner Owners
180 Process 2 Par Process Display
181 Process 2 Scale Process Display
182-189 Process 2 Txt 1-8 Process Display
190 Motor NP Volts Setup
191 Motor NP Amps Setup
192 Flux Amps Ref Motor Control
193 KP Amps Advanced Setup
194 IR Drop Volts Motor Control
195 Slip Comp Gain Feature Select
198 Rated VT Amps Ratings
199 Rated VT kW Ratings
200 Flux Up Time Motor Control
201 Motor OL Fault Faults
202 Motor OL Count Metering
203 VT Scaling Setup
204 Ground Warning Faults
205 Latched Alarms 1 Diagnostics
206 Alarm Mask 1 Masks
207 Fault Data Faults
212 DC Bus Memory Diagnostics
213 PI Config Process PI
214 PI Status Process PI
215 PI Ref Select Process PI
216 PI Fdbk Select Process PI
217 PI Reference Process PI
218 PI Feedback Process PI
219 PI Error Process PI
220 PI Output Process PI
221 KI Process Process PI
222 KP Process Process PI
223 PI Neg Limit Process PI
224 PI Pos Limit Process PI
225 PI Preload Process PI
226 Shear Pin Fault Faults
227 Adaptive I Lim Setup
228 LLoss Restart Feature Select
229 Freq Ref SqRoot Frequency Set
230 Save MOP Ref Frequency Set
231 Hold Level Sel Advanced Setup
232 Current Lmt Sel Setup
233 Anlg Out 0 Abs Analog I/O
234/235 Anlg Out 0 Lo/Hi Analog I/O
236 Drive Status 2 Diagnostics
237/238 Anlg In 0 Lo/Hi Analog I/O
239/240 Anlg In 1 Lo/Hi Analog I/O
241 Input Mode Setup + Digital I/O
242-247 TB3 Term Sel Digital I/O
248/249 Anlg In 2 Lo/Hi Analog I/O
250 Anlg Signal Loss Analog I/O
251 Cntrl Board Rev Ratings
252/253 Slot A/B Option Analog I/O
254 Pulse Freq Metering
255 Slip Adder Encoder Feedback
256 Line Loss Mode Feature Select
264 Pulse In Scale Freq. Set + Digital I/O
267 Dig At Temp Digital I/O
268 Motor Therm Flt Faults
269 Drive Alarm 2 Diagnostics
270 Latched Alarms 2 Diagnostics
271 Alarm Mask 2 Masks
272 Meas. Volts Diagnostics
274 Anlg Out 1 Sel Analog I/O
275 Anlg Out 1 Lo Analog I/O
276 Anlg Out 1 Hi Analog I/O
277 Anlg Out 1 Abs Analog I/O
278 Anlg Out 1 Offst Analog I/O
279 Elapsed Run Time Metering
280 Pulse Out Select Digital I/O
281 Pulse Out Scale Digital I/O
282 Enc Count Scale Encoder Feedback
283 Encoder Counts Encoder Feedback
284 Encoder Loss Sel Encoder Feedback
286 Fault Status 2 Faults
287 Fault Alarms 2 Faults
288 Bus Regulation Feature Select
290 Load Loss Detect Feature Select
291 Load Loss Level Feature Select
292 Load Loss Time Feature Select
293 PI Max Error Digital I/O
303 Current Limit En Setup
304 Traverse Dec Feature Select
305 Traverse Mask Masks
306 Traverse Owner Owners
307 Sync Time Advanced Setup
308 Sync Mask Masks
309 Sync Owner Owners
310 Sync Loss Sel Motor Control
311 Sync Loss Gain Motor Control
312 Sync Loss Time Motor Control
313 Sync Loss Comp Motor Control
314 Braking Chopper Advanced Setup
315 Alt Type 2 Cmd Adapter I/O
316 Application Sts Diagnostics
317 Run/Accel Volts Motor Control
319 Speed Brake En Advanced Setup
320 Line Loss Volts Feature Select
321 Loss Recover Feature Select
322 Ride Thru Volts Feature Select
323 Min Bus Volts Feature Select
324 Stability Gain Motor Control
325 Bus Reg Level Feature Select
Max Bus Volts Feature Select
326 Remote CR Output Digital I/O
327 At Time Digital I/O
328 Max Enc Counts Encoder Feedback
329 Bidir In Offset Linear List
330 Phase Loss Mode Faults
331 Phase Loss Level Faults
332 Precharge Fault Faults
333 PWM Comp Time Motor Control
334 Break Freq/PWM Motor Control
335-371 SLx Logic Step Step Logic
336-372 SLx Logic Jump Step Logic
337-373 SLx Step Jump Step Logic
338-374 SLx Step Setting Step Logic
339-375 SLx Time Step Logic
340-376 SLx Encoder Cnts Step Logic
377 Current Step Step Logic
