Chapter 5, Human interface module, Him description – Rockwell Automation 1336Z SPIDER - FRN 2.xxx-5.xxx User Manual
Page 45: Him description –1
Chapter
5
Human Interface Module
Chapter 5 describes the various controls and indicators found on the
optional Human Interface Modules (HIMs). The material presented in
this chapter must be understood to perform the start-up procedure in
Chapter 6.
HIM Description
A handheld HIM can be connected to the drive at TB1 (using a 1202-
Cxx Option Cable) as Adapter 2, 3, 4 or 5 (see Adapter Definitions in
Chapter 2).
The HIM can be divided into two sections; Display Panel and Control
Panel. The Display Panel provides a means of programming the drive
and viewing the various operating parameters. The Control Panel
allows different drive functions to be controlled. Refer to Figure 5.1,
Figure 5.2 and the sections that follow for a description of the panels.
Important: The operation of some HIM functions will depend upon
drive parameter settings. The default parameter values
allow full HIM functionality.
