Installation/Wiring 1-5
PowerFlex 400 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22C-UM001I-EN-P
•
Mount the drive upright on a flat, vertical and level surface.
•
Protect the cooling fan by avoiding dust or metallic particles.
•
Do not expose to a corrosive atmosphere.
•
Protect from moisture and direct sunlight.
Maximum Surrounding Air Temperature
Mounting Considerations
Frame Screw Size Screw Torque
C M5 (#10-24) 2.45-2.94 N-m (22-26 lb.-in.)
D M8 (5/16 in.) 6.0-7.4 N-m (53.2-65.0 lb.-in.)
E M8 (5/16 in.) 8.8-10.8 N-m (78.0-95.3 lb.-in.)
F M10 (3/8 in.) 19.6-23.5 N-m (173.6-208.3 lb.-in.)
G M12 (1/2 in.) 33.5-41.0 N-m (296.5-362.9 lb.-in.)
H M12 (1/2 in.) 33.5-41.0 N-m (296.5-362.9 lb.-in.)
Frame Enclosure Rating Temperature
Range Minimum Mounting
Clearances
C IP 20/UL Open-Type -10° to 45°C
(14° to 113°F) See Figure 1.1 ,
Mounting Option A
IP 30/NEMA 1/UL Type 1 (1)
(1) Frame C drives require installation of the PowerFlex 400 IP 30/NEMA 1/UL Type 1
option kit to achieve this rating.
-10° to 45°C
(14° to 113°F) See Figure 1.1 ,
Mounting Option B
IP 20/UL Open-Type -10° to 50°C
(14° to 122°F) See Figure 1.1 ,
Mounting Option B
D IP 30/NEMA 1/UL Type 1 -10° to 45°C
(14° to 113°F) See Figure 1.2
E
F See Figure 1.3
G See Figure 1.4
H
