Rockwell Automation 22C PowerFlex 400 AC Drive FRN 1.xx - 7.xx User Manual
Page 114

3-56
Programming and Parameters
PowerFlex 400 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22C-UM001I-EN-P
Refer to
for details on the application of parameters R239
through R254.
R221...
R236
Options
(Cont.)
24 “Fault” (with FRN 7.xx
and later)
Relay output is inactive when power is applied to the drive
and is active when a fault occurs. This is inverted from Option
0, “Ready/Fault”.
R222 [Relay Out3 Level]
R225 [Relay Out4 Level]
R228 [Relay Out5 Level]
R231 [Relay Out6 Level]
R234 [Relay Out7 Level]
R237 [Relay Out8 Level]
Sets the trip point for the digital output relay if the value of [Relay OutX Sel] is 6, 7, 8, 9, 10 or 12.
Values
Default:
0.0
Min/Max:
0.0/9999
Display:
0.1
[Relay OutX Select] Setting
[Relay OutX Level] Min/Max
6
7
8
9
10
12
0/320 Hz
0/180%
0/815 Volts
0/100%
1/180 degs
0/1
R239 [Aux Motor Mode]
Enables operation of the auxiliary motor control modes when in PID mode.
Options
0 “Disabled” (Default)
1 “Enabled”
