Supplemental Drive Information

A-5

Publication 22C-UM001I-EN-P

Control Outputs Relay:

Quantity:

(2) Programmable Form C

Specification

Resistive Rating:
Inductive Rating:

3.0A at 30V DC, 3.0A at 125V, 3.0A at 240V AC
0.5A at 30V DC, 0.5A at 125V, 0.5A at 240V AC

Optional
Relay Card:

Quantity:

(6) Optional Programmable Form A
(Not available for Frame C drives.)

Specification

Resistive Rating:

Inductive Rating:

0.1A at 30V DC Class II circuits, 3.0A at 125V,
3.0A at 240V AC
0.1A at 30V DC Class II circuits, 3.0A at 125V
3.0A at 240V AC

Opto:

Quantity:

(1) Programmable

Specification:

30V DC, 50mA Non-inductive

Analog:

Quantity:

(2) Non-Isolated, 0-10V or 4-20mA

Specification

Resolution:
0 to 10V DC Analog:
4-20mA Analog:

10-bit
1k ohm minimum
525 ohm maximum

Keypad

Display:

Integral 2 line by 16 character LCD with (5) LED Indicators

Languages: English, Français, Español, Italiano, Deutsch, Português, Nederlands

Communication Type:

Serial (RS485)

Supported
Protocols
(Standard):

Drive Serial Interface (DSI)
Modbus RTU
Metasys N2
P1 - Floor Level Network (FLN)

Supported
Protocols
(Optional):

BACnet
DeviceNet
EtherNet/IP
PROFIBUS DP
ControlNet
LonWorks

Software
(Optional):

Windows Based
Pocket PC/Windows Mobile 2003

Category

Specification
