Accessories and Dimensions
B-3
PowerFlex 400 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22C-UM001I-EN-P
Table B.5 Bulletin 1321-3R Series Line Reactors – 380-480V, 60 Hz, Three-Phase
kW
HP
Fundamental
Amps
Maximum
Continuous
Amps
Inductance
Watts
Loss
Catalog Number
IP00
(Open Style)
IP11
(NEMA Type 1)
3% Impedance
2.2
3.0
8
12
5
25.3
1321-3R8-C
1321-3RA8-C
4.0
5.0
12
18
2.5
31
1321-3R12-B
1321-3RA12-B
5.5
7.5
12
18
2.5
31
1321-3R12-B
1321-3RA12-B
7.5
10
18
27
1.5
43
1321-3R18-B
1321-3RA18-B
11
15
25
37.5
1.2
52
1321-3R25-B
1321-3RA25-B
15
20
35
52.5
0.8
54
1321-3R35-B
1321-3RA35-B
18.5
25
35
52.5
0.8
54
1321-3R35-B
1321-3RA35-B
22
30
45
67.5
0.7
62
1321-3R45-B
1321-3RA45-B
30
40
55
82.5
0.5
67
1321-3R55-B
1321-3RA55-B
37
50
80
120
0.4
86
1321-3R80-B
1321-3RA80-B
45
60
80
120
0.4
86
1321-3R80-B
1321-3RA80-B
55
75
100
150
0.3
84
1321-3R100-B
1321-3RA100-B
75
100
130
195
0.2
180
1321-3R130-B
1321-3RA130-B
90
125
160
240
0.15
149
1321-3R160-B
1321-3RA160-B
110
150
200
300
0.11
168
1321-3R200-B
1321-3RA200-B
132
200
250
375
0.09
231
1321-3RB250-B 1321-3RAB250-B
160
250
320
480
0.075
264
1321-3RB320-B 1321-3RAB320-B
200
300
400
560
0.06
333
1321-3RB400-B 1321-3RAB400-B
250
350
500
700
0.05
340
1321-3R500-B
1321-3RA500-B
5% Impedance
2.2
3.0
8
12
7.5
28
1321-3R8-D
1321-3RA8-D
4.0
5.0
12
18
4.2
41
1321-3R12-C
1321-3RA12-C
5.5
7.5
12
18
4.2
41
1321-3R12-C
1321-3RA12-C
7.5
10
18
27
2.5
43
1321-3R18-C
1321-3RA18-C
11
15
25
37.5
2.0
61
1321-3R25-C
1321-3RA25-C
15
20
35
52.5
1.2
54
1321-3R35-C
1321-3RA35-C
18.5
25
35
52.5
1.2
54
1321-3R35-C
1321-3RA35-C
22
30
45
67.5
1.2
65
1321-3R45-C
1321-3RA45-C
30
40
55
82.5
0.85
71
1321-3R55-C
1321-3RA550-C
37
50
80
120
0.7
96
1321-3R80-C
1321-3RA80-C
45
60
80
120
0.7
96
1321-3R80-C
1321-3RA80-C
55
75
100
150
0.45
108
1321-3R100-C
1321-3RA100-C
75
100
130
195
0.3
128
1321-3R130-C
1321-3RA130-C
90
125
160
240
0.23
138
1321-3R160-C
1321-3RA160-C
110
150
200
300
0.185
146
1321-3R200-C
1321-3RA200-C
132
200
250
375
0.15
219
1321-3RB250-C 1321-3RAB250-C
160
250
320
480
0.125
351
1321-3RB320-C 1321-3RAB320-C
200
300
400
560
0.105
293
1321-3RB400-C 1321-3RAB400-C
250
350
500
700
0.085
422
1321-3R500-C
1321-3RA500-C
