B-6
Accessories and Dimensions
PowerFlex 400 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22C-UM001I-EN-P
Table B.9 Communication Option Kits and Accessories
Item
Description
Catalog Number
BACnet® MS/TP
RS-485 Communication
Adapter
Embedded communication options for use with the
PowerFlex family of drives.
Requires a Communication Adapter Cover when
used with Frame C PowerFlex 400 drives (Ordered
Separately).
22-COMM-B
ControlNet™
Communication Adapter
22-COMM-C
DeviceNet™
Communication Adapter
22-COMM-D
EtherNet/IP™
Communication Adapter
22-COMM-E
LonWorks™
Communication Adapter
22-COMM-L
PROFIBUS™ DP
Communication Adapter
22-COMM-P
External DSI™
Communications Kit
External mounting kit for 22-COMM communication
adapter options.
22-XCOMM-
DC-BASE
External Comms Power
Supply
Optional 100-240V AC Power Supply for External
DSI Communications Kit.
20-XCOMM-
AC-PS1
Compact I/O Module
3 Channel.
1769-SM2
Communication Adapter
Cover
Cover that houses the communication adapter.
Frame C Drive
22C-CCC
Serial Converter Module
(RS485 to RS232)
Provides serial communication via DF1 protocol for
use with DriveExplorer and DriveExecutive software.
Includes:
DSI to RS232 serial converter (one)
1203-SFC serial cable (one)
22-RJ45CBL-C20 cable (one)
DriveExplorer Lite CD (one)
22-SCM-232
DSI Cable
2.0 meter RJ45 to RJ45 cable, male to male
connectors.
22-RJ45CBL-C20
Serial Cable
2.0 meter serial cable with a locking low profile
connector to connect to the serial converter and a
9-pin sub-miniature D female connector to connect to
a computer.
1203-SFC
Serial Null Cable
Converter
For use when connecting the serial converter to
DriveExplorer on a handheld PC.
1203-SNM
Universal Serial Bus™
(USB) Converter
Includes 2m USB, 20-HIM-H10 & 22-HIM-H10
cables.
1203-USB
Splitter Cable
RJ45 one to two port splitter cable
AK-U0-RJ45-SC1
Terminating Resistors
RJ45 120 Ohm resistors (2 pieces)
AK-U0-RJ45-TR1
Terminal Block
RJ45 Two position terminal block (5 pieces)
AK-U0-RJ45-TB2P
DriveExplorer Software
(CD-ROM) Version 3.01
or later
Windows based software package that provides an
intuitive means for monitoring or configuring
Allen-Bradley drives and communication adapters
online.
Compatibility:
Windows 95, 98, ME, NT 4.0 (Service Pack 3 or
later), 2000, XP and CE
(1)
(1)
See www.ab.com/drives/driveexplorer.htm for supported devices.
9306-4EXP01ENE
DriveExecutive software
(CD-ROM) Version 1.01
or later
Windows based software package that provides an
intuitive means for monitoring or configuring
Allen-Bradley drives and communication adapters
online and offline.
Compatibility:
Windows 98, ME, NT 4.0 (Service Pack 3 or later),
2000 and XP
9303-4DTE01ENE
Serial Flash Firmware
Kit
Use a PC to update drive firmware.
AK-U9-FLSH1
