B-2
Accessories and Dimensions
PowerFlex 400 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22C-UM001I-EN-P
Table B.3 PowerFlex 400 Flange Mount Drives
Table B.4 Bulletin 1321-3R Series Line Reactors – 200-240V, 60 Hz, Three-Phase
Drive Ratings
Catalog Number
Frame
Size
Input Voltage
kW
HP
Output Current
45°C
50°C
240V 50/60 Hz
3-Phase
2.2
3
12A
12A
22C-B012F103
C
3.7
5
17.5A
17.5A
22C-B017F103
C
5.5
7.5
24A
24A
22C-B024F103
C
7.5
10
33A
33A
22C-B033F103
C
480V 50/60 Hz
3-Phase
2.2
3
6.0A
6.0A
22C-D6P0F103
C
4.0
5
10A
10A
22C-D010F103
C
5.5
7.5
12A
12A
22C-D012F103
C
7.5
10
17A
17A
22C-D017F103
C
11
15
22A
22A
22C-D022F103
(1)
(1)
A DC bus inductor is required. See
for ordering information.
C
15
20
30A
27A
22C-D030F103
C
kW
HP
Fundamental
Amps
Maximum
Continuous
Amps
Inductance
mh
Watts
Loss
Catalog Number
IP00
(Open Style)
IP11
(NEMA Type 1)
3% Impedance
2.2
3.0
12
18
1.25
26
1321-3R12-A
1321-3RA12-A
3.7
5.0
18
27
0.8
36
1321-3R18-A
1321-3RA18-A
5.5
7.5
25
37.5
0.5
48
1321-3R25-A
1321-3RA25-A
7.5
10
35
52.5
0.4
49
1321-3R35-A
1321-3RA35-A
11
15
45
67.5
0.3
54
1321-3R45-A
1321-3RA45-A
15
20
55
82.5
0.25
64
1321-3R55-A
1321-3RA55-A
18.5
25
80
120
0.2
82
1321-3R80-A
1321-3RA80-A
22
30
80
120
0.2
82
1321-3R80-A
1321-3RA80-A
30
40
100
150
0.15
94
1321-3R100-A
1321-3RA100-A
37
50
130
195
0.1
108
1321-3R130-A
1321-3RA130-A
5% Impedance
2.2
3.0
12
18
2.5
31
1321-3R12-B
1321-3RA12-B
3.7
5.0
18
27
1.5
43
1321-3R18-B
1321-3RA18-B
5.5
7.5
25
37.5
1.2
52
1321-3R25-B
1321-3RA25-B
7.5
10
35
52.5
0.8
54
1321-3R35-B
1321-3RA35-B
11
15
45
67.5
0.7
62
1321-3R45-B
1321-3RA45-B
15
20
55
82.5
0.5
67
1321-3R55-B
1321-3RA55-B
18.5
25
80
120
0.4
86
1321-3R80-B
1321-3RA80-B
22
30
80
120
0.4
86
1321-3R80-B
1321-3RA80-B
30
40
100
150
0.3
84
1321-3R100-B
1321-3RA100-B
37
50
130
195
0.2
180
1321-3R130-B
1321-3RA130-B
