The L_DAC_DataConversion library
L_DAC_2BytesToWord - type converter
96
Lenze · Commissioning of Lenze drives · 1.3 EN - 06/2014
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
11.17 L_DAC_2BytesToWord - type converter
This function converts two input values of the "BYTE" type to an output value of the "WORD" type.
Inputs
Output signal
L_DAC_2BytesToWord - value of the "WORD" type according to the input values transferred
11.18 L_DAC_2WordsToDWord - type converter
This function converts two input values of the "WORD" type to an output value of the "DWORD"
type.
Inputs
Output signal
L_DAC_2WordsToDWord - value of the "DOUBLE WORD" type according to the input values
transferred
Function library: L_DAC_DataConversion
Runtime software licence:  LPC 1x00  MPC 1x00  MPC 2xx0  MPC 3x00
L_DAC_2BytesToWord
BYTE ⎯ byInput1 L_DAC_2BytesToWord ⎯ WORD
BYTE ⎯ byInput2
Identifier/data type Information/possible settings
byInput1
BYTE
Input value 1 ≡ bit 0 ... bit 7 of L_DAC_2BytesToWord
byInput2
BYTE
Input value 2 ≡ bit 8 ... bit 15 of L_DAC_2BytesToWord
Function library: L_DAC_DataConversion
Runtime software licence:  LPC 1x00  MPC 1x00  MPC 2xx0  MPC 3x00
L_DAC_2WordsToDWord
WORD ⎯ wInput1 L_DAC_2WordsTo
DWORD
⎯ DWORD
WORD ⎯ wInput2
Identifier/data type Information/possible settings
wInput1
WORD
Input value 1 ≡ bit 0 ... bit 15 of L_DAC_2WordsToDWord
wInput2
WORD
Input value 2 ≡ bit 16 ... bit 31 of L_DAC_2WordsToDWord
