The L_LCB_LogicControlBasic library
L_LCB_GenericDrive
130
Lenze · Commissioning of Lenze drives · 1.3 EN - 06/2014
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
13.10 L_LCB_GenericDrive
This FB serves to control any Lenze controller you like.
• Communication with the device is possible via CAN.
Input
Outputs
Function library: L_LCB_LogicControlBasic
Runtime software licence:  LPC 1x00  MPC 1x00  MPC 2xx0  MPC 3x00
L_LCB_GenericDrive
L_LCB_AXIS_REF ⎯ LogicAxis xError ⎯ BOOL
ARRAY[1..4] OF WORD ⎯ awTxData eError ⎯ L_LCB_Error
BOOL ⎯ xEnableInternalControl xInternalControlActive ⎯ BOOL
xCommunicationOK ⎯ BOOL
awRxData ⎯ ARRAY[1..4] OF WORD
Identifier/data type Information/possible settings
LogicAxis
L_LCB_AXIS_REF
Structural data for drive control
awTxData
ARRAY[1..4] OF WORD
Process data to be transmitted to the controller
xEnableInternalControl
BOOL
TRUE: The internal control of the controller can be activated via the "Internal
Control" button.
Identifier/data type Information/possible settings
xError
BOOL
TRUE: Error of POU active
eError
L_LCB_Error
Error number, error code
xInternalControlActive
BOOL
TRUE: The output signals that the xEnableInternalControl input and the Internal
Control button of the visualisation have been activated. Hence, all selections are
made via visualisation.
xCommunicationOk
BOOL
Status of bus communication
FALSE No bus communication active
TRUE Bus communication available
awRxData
ARRAY[1..4] OF WORD
Process data to be received by the controller
