The L_LCB_LogicControlBasic library
Overview of the functions and function blocks
114
Lenze · Commissioning of Lenze drives · 1.3 EN - 06/2014
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Enums
 L_LCB_AXISMODE ( 149)
 L_LCB_Error ( 115)
 L_LCB_LOGICDEVICE ( 150)
Function Blocks
DriveInterface
 L_LCB_AXIS_REF ( 115)
 L_LCB_AXIS_REF_CAN (internal use) ( 116)
 L_LCB_AXIS_REF_ETC (internal use) ( 116)
LogicDrives
 L_LCB_8400Drive ( 117)
 L_LCB_9400Drive ( 118)
 L_LCB_ActuatorSpeed ( 120)
 L_LCB_GenericDrive ( 130)
 L_LCB_TablePositioning ( 124)
Scaling
Data converter
 L_LCB_Norm_aToNorm_n - signal converter ( 131)
 L_LCB_Norm_nToNorm_a - signal converter ( 131)
 L_LCB_Norm_nToSpeed_s - signal converter ( 132)
 L_LCB_Speed_nToNorm_r - signal converter ( 134)
 L_LCB_Speed_rToNorm_n - signal converter ( 134)
 L_LCB_Speed_sToNorm_n - signal converter ( 135)
 L_LCB_Speed_sToSpeed_v - signal converter ( 136)
 L_LCB_Speed_vToSpeed_s - signal converter ( 136)
Data sinks and sources
 L_LCB_GetAxisData - read out machine parameters from
axis data ( 138)

L_LCB_GetPosition - conversion block ( 139)
 L_LCB_GetSpeed - conversion block ( 140)
 L_LCB_SetAxisData - machine parameters ( 141)
 L_LCB_SetPosition - position value conversion ( 142)
 L_LCB_SetSpeed - speed value conversion ( 143)
Signal conversion
 L_LCB_AccToUnit - acceleration value conversion ( 144)
 L_LCB_PosToUnit - position value conversion ( 145)
 L_LCB_SpeedToUnit - speed value conversion ( 146)
 L_LCB_UnitToAcc - acceleration value conversion ( 147)
 L_LCB_UnitToPos - position value conversion ( 148)
 L_LCB_UnitToSpeed - speed value conversion ( 149)
TaskInfo
 L_LCB_TaskCycle - read in task time ( 137)
