Lenze PLC Designer R3-x - Manual (Page 119)

Lenze · Commissioning of Lenze drives · 1.3 EN - 06/2014
119
The L_LCB_LogicControlBasic library
L_LCB_9400Drive
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
iLPort16In2
INT
LPort16In2 interface of the 9400 controller
iLPort16In3
INT
LPort16In3 interface of the 9400 controller
Identifier/data type Information/possible settings
xError
BOOL
"Error" status signal
FALSE Conversion carried out without errors
TRUE Error during the conversion
eError
L_LCB_Error
Error number, error code
xInternalControlActive
BOOL
TRUE: The output signals that the xEnableInternalControl input and the Internal
Control button of the visualisation have been activated.
• The control via visualisation is activated.
xCommunicationOk
BOOL
Status of bus communication
FALSE No bus communication active
TRUE Bus communication available
uiLPortAxisOut1_wStatus
UINT
LPortAxisOut1.wStatus interface of the 9400 controller
diLPortAxisOut1_dnOut1
INT
LPortAxisOut1.nOut1 interface of the 9400 controller
diLPortAxisOut1_dnOut2
DINT
LPortAxisOut1.dnOut2 interface of the 9400 controller
uiLPortStatus1
UINT
LPortStatus1 interface of the 9400 controller
uiLPortStatus2
UINT
LPortStatus2 interface of the 9400 controller
diLPort32Out1
DINT
LPort32Out1 interface of the 9400 controller
diLPort32Out2
DINT
LPort32Out2 interface of the 9400 controller
diLPort32Out3
DINT
LPort32Out3 interface of the 9400 controller
iLPort16Out1
INT
LPort16Out1 interface of the 9400 controller
iLPort16Out2
INT
LPort16Out2 interface of the 9400 controller
iLPort16Out3
INT
LPort16Out3 interface of the 9400 controller
Identifier/data type Information/possible settings
