The L_LCB_LogicControlBasic library
L_LCB_TablePositioning
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
xHomingActive
BOOL
Status signal "Homing activated
xHomingDone
BOOL
Status signal "Homing completed"
xHomePosAvailable
BOOL
Status signal "Home position is known"
xManualActive
BOOL
Status signal "Manual jog active"
xProfileActive
BOOL
Status signal " Positioning active"
xProfileDone
BOOL
Status signal " Positioning completed"
xProfileInTarget
BOOL
Status signal "Target position reached"
xHW_LimitSwitchPos
BOOL
Positive hardware limit switch
xHW_LimitSwitchNeg
BOOL
Negative hardware limit switch
rSpeedActual
REAL
Current speed in [%]
rPositionActual
REAL
Current position in [Units]
Identifier/data type Information/possible settings
