Overview of device descriptions
9400 HighLine C - Overview of indices
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.13
9400 HighLine C - Overview of indices
• The process data received are copied to the awReceiveData element of the L_LCB_AXIS_REF
instance.
• The process data to be transmitted are copied from the awTransmitData element of the
L_LCB_AXIS_REF instance.
The table provides an overview which index can be found where.
Application variable
Name CAN
Index CAN
Name EtherCAT
Index EtherCAT
awTransmitData[1]
LPortAxisIn1
_wControl
0xA580/01
LPortAxisIn1
_wControl
0xA580/01
awTransmitData[2]
LPortAxisIn1
_nIn1
0xA540/01
LPortAxisIn1
_nIn1
0xA540/01
awTransmitData[3]
LPortAxisIn1
_dnIn2
0xA640/01
LPortAxisIn1
_dnIn2
0xA640/01
awTransmitData[4]
awTransmitData[5]
LPortControl1
0xA580/02
LPortControl1
0xA580/02
awTransmitData[6]
LPortControl2
0xA580/03
LPortControl2
0xA580/03
awTransmitData[7]
LPort32In1
0xA640/02
LPort32In1
0xA640/02
awTransmitData[8]
awTransmitData[9]
LPort32In2
0xA640/03
LPort32In2
0xA640/03
awTransmitData[10]
awTransmitData[11]
LPort32In3
0xA640/04
LPort32In3
0xA640/04
awTransmitData[12]
awTransmitData[13]
LPort16In1
0xA540/02
LPort16In1
0xA540/02
awTransmitData[14]
LPort16In2
0xA540/03
LPort16In2
0xA540/03
awTransmitData[15]
LPort16In3
0xA540/04
LPort16In3
0xA540/04
awTransmitData[16]
-
-
-
-
awReceiveData[1]
LPortAxisOut1
_wStatus
0xA100/01
LPortAxisOut1
_wStatus
0xA100/01
awReceiveData[2]
LPortAxisOut1
_nOut1
0xA0C0/01
LPortAxisOut1
_nOut1
0xA0C0/01
awReceiveData[3]
LPortAxisOut1
_dnOut2
0xA1C0/01
LPortAxisOut1
_dnOut2
0xA1C0/01
awReceiveData[4]
awReceiveData[5]
LPortStatus1
0xA100/02
LPortStatus1
0xA100/02
awReceiveData[6]
LPortStatus2
0xA100/03
LPortStatus2
0xA100/03
awReceiveData[7]
LPort32Out1
0xA1C0/02
LPort32Out1
0xA1C0/02
awReceiveData[8]
awReceiveData[9]
LPort32Out2
0xA1C0/03
LPort32Out2
0xA1C0/03
awReceiveData[10]
awReceiveData[11]
LPort32Out3
0xA1C0/04
LPort32Out3
0xA1C0/04
awReceiveData[12]
awReceiveData[13]
LPort16Out1
0xA0C0/02
LPort16Out1
0xA0C0/02
awReceiveData[14]
LPort16Out2
0xA0C0/03
LPort16Out2
0xA0C0/03
awReceiveData[15]
LPort16Out3
0xA0C0/04
LPort16Out3
0xA0C0/04
awReceiveData[16]
-
-
-
-
