Working with the sample projects
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7 Working with the sample projects
The ready-configured sample projects are to facilitate the work with the Lenze components for you.
They include established system configurations representing typical application cases. The
objective is to obtain an executable Lenze automation system by using low effort.
Depending on the application case, the sample projects can be optionally extended, and thus they
have to be adapted to the requirements in each case.
Where do I find the sample projects?
After a successful installation of the Lenze sample projects they can be found under:
ProgramsLenzeAppSamples
The sample projects are preconfigured for different bus systems.
• CAN projects contain the "_Can" code in the file name
• EtherCAT projects contain the "_ETC" code in the file name
From »PLC Designer« V3.3 the Application Samples are available as predefined »PLC Designer«
projects (*.project, ) when a new project is created.

How to proceed:
1. Creating a new project:
• File New project
• Select category Lenze Application Samples.
• Open the desired Application Sample.

Tip!
The »Engineer« sample projects are archived in ZIP format to allow you to send them for
instance by e-mail.
The »Engineer« supports project saving (FileSave archive) and project opening
(FileOpen archive) in ZIP format.
