The L_LCB_LogicControlBasic library
L_LCB_SetAxisData - machine parameters
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
13.23 L_LCB_SetAxisData - machine parameters
With this FB the machine parameters of a higher-level drive can be mapped. The FB conditions the
machine parameters, which you specify in the physical units of the machine via parameters, for the
internal representation.
• The FB outputs a pointer to the data structure with the prepared machine parameters at the
output scAxisData.
• In order to pass the machine parameters to an FB which requires these data for internal
calculations, the output scAxisData is to be connected to the input with the same name of the
corresponding FB.
Inputs
Function library: L_LCB_LogicControlBasic
Runtime software licence:  LPC 1x00  MPC 1x00  MPC 2xx0  MPC 3x00
L_LCB_SetAxisData
REAL ⎯ rFeedConstant diCycleLength_p ⎯ DINT
REAL ⎯ rCycleLength scAxisData ⎯ L_LCB_SetAxisData -
machine parameters
DWORD ⎯ dwGearNumerator
DWORD ⎯ dwGearDenominator
REAL ⎯ rReferenceSpeed
STRING ⎯ sAxisName
L_LCB_AXISMODE ⎯ eMode
DINT ⎯ dwResolution
Identifier/data type Information/possible settings
rFeedConstant
REAL
Feed constant, initial value: 360.0 units.
rCycleLength
REAL
Cycle length, initial value: 360.0 units.
dwGearNumerator
DWORD
Gearbox factor numerator, initial value: 1.
dwGearDenominator
DWORD
Gearbox factor denominator, initial value: 1.
rReferenceSpeed
REAL
Reference speed
sAxisName
STRING(16)
Axis name
eMode
L_LCB_AXISMODE
Traversing range
• 0 Unlimited (Lenze setting)
• 1 limited
• 2 modulo
dwResolution
DINT
Resolution of one revolution
