ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-294
© 2000, ADC Telecommunications, Inc.
TAP-101
Page 8 of 13
Table 101-1. Alarm Descriptions/Conditions, continued
DS3 MUX ALARMS, AID = EQPT-MXW#, EQPT-MXP#
CONDITION DESCRIPTION
BOARD FAIL Fatal hardware or software error
COMM FAIL MPU unable to communicate with DS3 MUX
CONFIG MISMATCH Configuration mismatch with mate module
PROTECT COMM FAIL Unable to communicate with mate module (Working-Protect)
ODS2 ALARMS, AID = EQPT-LIU#
CONDITION DESCRIPTION
BOARD FAIL Fatal hardware or software error
COMM FAIL MPU unable to communicate with ODS2
CONFIG MISMATCH Configuration mismatch with mate module or remote module
RMT-HSKP1 or RMT-
HSKP2 Housekeeping alarm detected at remote end (QFLC or QLX)
PROTECT COMM FAIL Unable to communicate with mate module (Working-Protect)
OPTICAL COMM FAIL Unable to communicate with remote module
VERSION MISMATCH Incompatible software versions with mate module or remote module
ODS2 ALARMS, AID = T1
CONDITION DESCRIPTION
LOOPED BACK Signal looped back at either ODS2 or remote
RECEIVE LOS Loss Of Signal detected at remote end (QFLC or QLX)
TRANSMIT LOS Transmit Loss of Signal detected at remote end (QFLC or QLX),
hardware failure
ODS2 ALARMS, AID = T2
CONDITION DESCRIPTION
APS LIMIT REACHED APS limit of 3 switches in 24 hours has been reached, APS disabled
FORCE TO WORK Working module forced online, APS disabled
FORCE TO PROT Protect module forced online, APS disabled
LASER DEGRADE Laser driver degradation, hardware failure
OPTICAL LOF Optical Loss of Frame
OPTICAL LOS Optical Loss Of Signal
T-BER Bit Error Rate exceeds user-defined threshold
(continued)
