HLX AND HRX STATUS DISPLAY
Summary: This procedure provides instructions for displaying the status of the HLX modules
installed in the central office chassis, the associated HLX modules at the remote end of the
circuit, and the HRX modules.
Note: Press CONTROL-A for help information about moving around and editing fields.
1. Use the arrow keys to select Display HLX Status from the Display Status menu. Press Enter
or Return.
2. Use the arrow keys to select HLX Status from the Display Status menu. Press Enter or
Return. Refer to Table 548-1 for descriptions of status screens, and status locations
displayed on the screens.
3. Move to the Group toggle field. Select group number 1, 2, 3, 4, 5, 6, or 7.
Reference: TAD-106 Access Identifier
4. Move to the Slot toggle field. Select slot number 1, 2, 3, or 4.
Stop! You have completed this procedure.
Table 548-1. Status Locations
HLXC/HLXR
SYSTEM TYPE MPU SOFTWARE
VERSION STATUS
SCREEN SCREEN
FIGURE STATUS
LOCATIONS STATUS LOCATION
DESCRIPTIONS
No HRX V5.1 HLX Status Figure 548-1 N/A None
One HRX V5.1 HLX/HRX
Status Figure 548-2 C-SIDE,
R-SIDE
Figure 548-4
One or two
HRXs V5.2 HLX/HRX
Status Figure 548-3 CRP1, RRP1,
CRP2, RRP2
Figure 548-5
Note: If one or no HRX is present in a two-repeater system, or no HRX is present in a one-repeater
system, the screens will show “N/A” in the related HRX column.
