ADC Soneplex Broadband System - Manual (Page 314)

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-291
© 2000, ADC Telecommunications, Inc.
TAP-101
Page 5 of 13
ALARM HISTORY
Legend:
Access ID=Identifier[-]Shelf-Grp-Slot[-Site(1=Lcl,2=Rmt) | -Loop(1=Lp 1,2=Lp 2)]
Date Time Access ID Locn Circuit ID Condition St
-------- -------- ---------------- ---- -------------------- ---------------- --
01/03/95 22:37:00 T1-6-1-2 FEND LOF CL
01/03/95 22:37:00 T1-6-1-1 FEND LOF CL
01/03/95 22:36:57 HDSL-1-6-1-2 NEND LOF CL
01/03/95 22:36:57 HDSL-1-6-1-1 NEND LOF CL
01/03/95 22:36:52 HDSL-1-6-1-2 FEND LOF MJ
01/03/95 22:36:52 HDSL-1-6-1-1 FEND LOF MJ
01/03/95 22:36:48 HDSL-1-6-1-2 FEND LOF CL
01/03/95 22:36:48 HDSL-1-6-1-2 NEND RECOVERY CL
01/03/95 22:36:48 HDSL-1-6-1-1 FEND LOF CL
01/03/95 22:36:48 HDSL-1-6-1-1 NEND RECOVERY CL
01/03/95 22:36:36 HDSL-1-6-1-2 NEND RECOVERY MN
01/03/95 22:36:36 HDSL-1-6-1-1 NEND RECOVERY MN
01/03/95 22:36:34 HDSL-1-6-1-2 NEND RECOVERY CL
01/03/95 22:36:34 HDSL-1-6-1-1 NEND RECOVERY CL
01/03/95 22:36:32 HDSL-1-6-1-1 NEND DC CONTINUITY CL
01/03/95 22:36:25 HDSL-1-6-1-2 NEND RECOVERY MN
01/03/95 22:36:25 HDSL-1-6-1-1 NEND RECOVERY MN
Page 1 of 2 Press CONTROL-A for assistance
6677-B
Figure 101-3. Alarm History Screen (MPU V5.1) (Sample)
11378-A
ALARM HISTORY
Legend:
Access ID=Identifier[-]Shelf-Grp-Slot[-Site(1=Lcl,2=Rmt) | -Loop(1=Lp 1,2=Lp 2)]
01/03/98 22:37:00 T1-6-1-2 FEND LOF CL
01/03/98 22:37:00 T1-6-1-1 FEND LOF CL
01/03/98 22:36:57 HDSL-1-6-1-2 RRP1 LOF CL
01/03/98 22:36:57 HDSL-1-6-1-1 RRP1 LOF CL
01/03/98 22:36:52 HDSL-1-6-1-2 CRP1 LOF MJ
01/03/98 22:36:52 HDSL-1-6-1-1 CRP1 LOF MJ
01/03/98 22:36:48 HDSL-1-6-1-2 CRP1 LOF CL
01/03/98 22:36:48 HDSL-1-6-1-2 RRP1 RECOVERY CL
01/03/98 22:36:48 HDSL-1-6-1-1 CRP1 LOF CL
01/03/98 22:36:48 HDSL-1-6-1-1 RRP1 RECOVERY CL
01/03/98 22:36:36 HDSL-1-6-1-2 RRP1 RECOVERY MN
01/03/98 22:36:36 HDSL-1-6-1-1 RRP1 RECOVERY MN
01/03/98 22:36:34 HDSL-1-6-1-2 RRP1 RECOVERY CL
01/03/98 22:36:34 HDSL-1-6-1-1 RRP1 RECOVERY CL
01/03/98 22:36:32 HDSL-1-6-1-1 RRP1 DC CONTINUITY CL
Page 1 of 2 Press CONTROL-A for assistance
01/03/98 22:38:57 EQPT-LIU1-1-1-2 HLXR INCOMPATIBLE CL
01/03/98 22:38:54 EQPT-LIU1-1-1-2 HLXR INCOMPATIBLE MN
Date Time Access ID Locn Circuit ID Condition St
-------- -------- --------------- ---- ------------------- --------------- --
Figure 101-4. Alarm History Screen (MPU V5.2) (Sample)
