ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-268
© 2000, ADC Telecommunications, Inc.
TAD-104
Page 3 of 11
Table 104-1. DS1 Signal Routing
DS1
SIGNAL
GROUP-
SLOT
NUMBER
DS1
SIGNAL
GROUP-
SLOT
NUMBER
DS1
SIGNAL
GROUP-
SLOT
NUMBER
DS1
SIGNAL
GROUP-
SLOT
NUMBER
1 1-1 8 2-4 15 4-3 22 6-2
2 1-2 9 3-1 16 4-4 23 6-3
3 1-3 10 3-2 17 5-1 24 6-4
4 1-4 11 3-3 18 5-2 25 7-1
5 2-1 12 3-4 19 5-3 26 7-2
6 2-2 13 4-1 20 5-4 27 7-3
7 2-3 14 4-2 21 6-1 28 7-4
Table 104-2. TBOS Abbreviations and Acronyms
ABBREVIATION/
ACRONYM DESCRIPTION
ABBREVIATION/
ACRONYM DESCRIPTION
ACO Alarm Cut Off LPBK Loopback
ALM Alarm L/R Local/Remote
APS Automatic Protection Switching LSP Low Speed Protect Module
CL Clear LSW Low Speed Working Module
CUS Customer MPU Main Processing Unit
D DS1 Signal MX DS3 MUX or DS3MAP Module Pair
DIS Disable MXP DS3 MUX or DS3MAP Protect Module
ENAB Enable MXW DS3 MUX or DS3MAP Working Module
EQ Equipped NET Network
EQPT Equipment OOS Out-of-Service
FAC Facility P, PROT Protect
HS High Speed REM, RMT Remote
HSKP Housekeeping REQ Request
HSP High Speed Protect Module RX Receive
HSW High Speed Working Module SIG Signal
HLXC HDSL Terminal Unit CO Side SNR Signal to Noise Ratio
HLXR HDSL Terminal Unit Remote Side SW Switch
IS In-Service TX Transmit
L Low Speed Slot UNEQ Unequipped
LBO Line Build Out UNPROT Unprotected
LCL, LOC Local W, WKG Working
LOCK Lockout
