Figure 575-1, Figure 575-2, Dlp-575 – ADC Soneplex Broadband System User Manual
Page 264: Page 3 of 5, Figure 575-1. tau module front panel
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-241
© 2000, ADC Telecommunications, Inc.
DLP-575
Page 3 of 5
TAU
B8ZS
STATUS
LINE CODE
INTRUSIVE
TEST
D
S
1
RX
TX
5842-B
Figure 575-1. TAU Module Front Panel
6188-B
TEST ACCESS UNIT STATUS/COMMANDS
Group: 1 DS1#: 1
Drop Direction Insert Direction
============== ================
Status : NONE NONE
Command :
TAU Present Status: YES
Press CONTROL-A For Assistance
Figure 575-2. Test Access Unit Status/Commands Screen
