ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-179
© 2000, ADC Telecommunications, Inc.
DLP-555
Page 2 of 2
7. After a download is finished, a message appears to indicate whether the download was
successful or unsuccessful.
•
If successful, the MPU will reboot automatically to ensure that the configuration
database takes effect. Stop! You have completed this procedure.
•
If unsuccessful, repeat Steps 3 through 6.
5323-A
SYSTEM MAINTENANCE
1. Force/APS Commands
2. Reset/LED Test Commands
3. Execute ACO (Alarm Cut-Off)
4. Loopback Status/Commands
5. Display Inventory
6. Display Circuit IDs
7. Upload/Download Commands
8. Test Access Unit Commands
Press CONTROL-A For Assistance
Figure 555-1. System Maintenance Menu
9449-A
UPLOAD/DOWNLOAD COMMANDS
1. Execute Configuration Data Upload
2. Execute Configuration Data Download
3. Execute Software Download
Press CONTROL-A For Assistance
Figure 555-2. Upload/Download Commands Menu
