Dlp-545, Page 2 of 2, Figure 545-2. help screen – ADC Soneplex Broadband System User Manual

Page 179

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance

2-156
© 2000, ADC Telecommunications, Inc.

DLP-545

Page 2 of 2

HELP SCREEN - press any key to return to MENU

On MENU:

Unit Type:

M - MUX

+ - MUX-PLUS

X - MUX-ENHANCED

O - ODS2

H - HLX

R - RLX TAU Unit Type

D - DLX T - TAU

Q - QLX R - RTAU

Control-P - Jump to previous menu

Control-T - Jump to Main Menu

Control-R - Refresh this current menu

Control-A - Display this help screen

Control-D - Terminate user session (logout)

Equip State:

E - Equipped

U - Unequipped

P - Protected

14855-A

Figure 545-2. Help Screen
