TAD-106
Page 1 of 2
ACCESS IDENTIFIER
Summary:
Circuits displayed in the Craft Interface are identified by the Access Identifier (AID).
Figure 106-1
shows an example of a circuit with descriptions of each part of the AID. The DS3
signal is demultiplexed by the DS3 MUX into 28 DS1 signals and seven DS2 signals. See
for DS1 signal routing details. See
for DS2 signal routing details. See
T1-1-7-2-1
Shelf Number
Group Number: 1, 2, 3, 4, 5, 6, or 7
Site or Loop Number: 1 (Local or HDSL
Loop 1) or 2 (Remote or HDSL Loop 2)
Slot Number: 1, 2, 3, or 4
Circuit Identifier:
(T1, T2, T3 or HDSL)
CIRCUIT AID
EQUIPMENT AID
EQPT-LIU1-7-2-1
Equipment Type (LIU, MPU, MXP, MXW, TAU or EXT) and Shelf Number
Identifier for Equipment AID
Group Number: 1, 2, 3, 4, 5, 6, or 7
Slot Number: 1, 2, 3, or 4
Site or Loop Number: 1 (Local or HDSL
Loop 1) or 2 (Remote or HDSL Loop 2)
LIU = Line Interface Unit
MPU = Main Processor Unit
MXP = DS3 MUX (Protect)
MXW = DS# MUX (Working)
TAU = Remote Test Access Unit (RTAU)
EXT = External
14852-A
Figure 106-1. Access Identifier Display
