ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-118
© 2000, ADC Telecommunications, Inc.
DLP-534
Page 5 of 6
Table 534-1. RLX Configuration Fields, continued
FIELD TYPE OPTIONS DESCRIPTION DEFAULT
NID Loopback*† Toggle UNIT SWITCH Selects NID setting (either enabled [default]
or disabled) on the Version A RLX. When
the Version A is provisioned to function
like an NID, it supports inband and out-of-
band loopback codes. Version A only:
UNIT SWITCH
Version B only:
DISABLE
ENABLE Enables response to NID loopback codes
and overrides hardware configuration
settings.
DISABLE Disables response to NID loopback codes
and overrides hardware configuration
settings.
Loopback Activation
Code Input 16 binary characters
(0’s and 1’s) must be
entered. These codes can be set to any 16-bit binary
value except: all 0s, all 1s, or a value that is
already used in another 16-bit code. The
signal is sent inband. RLX units go to
loopup state when they are in an armed
state. Loopup is activated for selected units.
Detection time is 3 secs. 1101 0011 1101 0011
Loopback Deactivate
Code Input The signal is sent inband. Units in loopup
state go back to armed state. Detection time
is 5 secs. 1001 0011 1001 0011
Lpbk Timeout
Disable Code Input This disables the loopup time-out. Active
loopbacks stay up until deactivation or
disarm code is received. Detection time is 3
secs. 1101 0101 1101 0110
Loopback Timeout
Period Input Enter a number from 0
to 255 This represents the minutes the loopback
remains in effect before reverting to the
non-loopback state. Setting the loopback
time out period to 0 disables the time out
feature. 30 minutes
Network Keep Alive Toggle AIS If the system detects a LOS (Loss of Signal)
from the customer, an AIS is sent to the
network. AIS
DS1 CUTOFF If the system detects a LOS from the
customer, the signal is cut off and no signal
is transmitted to the network.
*Note: Unit switch settings (Pulse Equalization, Span Power, NID, and LBO) are shown on the bottom of the configuration screen.
†Note: The UNIT SWITCH option appears on screen for both RLX types, but is only functional for Version A.
(continued)
