Section 7. Installation
150
CRBasic Example 22. Constants to LONGs or FLOATs
Public I As Long
Public A1, A2
Const ID = 10
BeginProg
A1 = A2 + ID
I = ID * 5
EndProg
In CRBasic example Constants to LONGs or FLOATs
(p. 150),
I is an integer. A1
and A2 are FLOATS. The number 5 is loaded As FLOAT to add efficiently with
constant ID, which was compiled As FLOAT for the previous expression to avoid
an inefficient runtime conversion from LONG to FLOAT before each floating
point addition.
7.7.3.9.4 Logical Expressions
Measurements can indicate absence or presence of an event. For example, an RH
measurement of 100% indicates a condensation event such as fog, rain, or dew.
The CR3000 can render the state of the event into binary form for further
processing, i.e., the event is either occurring (true), or the event has not occurred
(false).
True = -1, False = 0
In all cases, the argument 0 is translated as FALSE in logical expressions; by
extension, any non-zero number is considered "non-FALSE." However, the
argument TRUE is predefined in the CR3000 operating system to only equal -1,
so only the argument -1 is always translated as TRUE. Consider the expression
If Condition(1) = TRUE Then ...
This condition is true only when Condition(1) = -1. If Condition(1) is any other
non-zero, the condition will not be found true because the constant TRUE is
predefined as -1 in the CR3000 system memory. By entering = TRUE, a literal
comparison is done. So, to be absolutely certain a function is true, it must be set
to TRUE or -1.
Note TRUE is -1 so that every bit is set high (-1 is &B11111111 for all four
bytes). This allows the AND operation to work correctly. The AND operation
does an AND boolean function on every bit, so TRUE AND X will be non-zero if
at least one of the bits in X is non-zero, i.e., if X is not zero. When a variable of
data type BOOLEAN is assigned any non-zero number, the CR3000 internally
converts it to -1.
The CR3000 is able to translate the conditions listed in table Binary Conditions of
TRUE and FALSE
(p. 151)
to binary form (-1 or 0), using the listed instructions and
saving the binary form in the memory location indicated. Table Logical
Expression Examples
(p. 151)
explains some logical expressions.
Non-Zero = True (Sometimes)
Any argument other than 0 or -1 will be translated as TRUE in some cases and
FALSE in other cases. While using only -1 as the numerical representation of
