NOTE:
For an XP10000 Disk Array, the MIX boards do not have MP4, 5, and 6 defined. So, when these
metrics are chosen, the utilization is shown as zero.
The Utilization metric is available for the DKAs that are associated with the concatenated RAID groups.
All the associated DKA pairs are displayed individually in the Resource list box on the Charts screen.
TIP:
For CHIPs that are not installed, the MP utilization shows zero.
Related Topics
• “ Front-end navigation path ” on page 269
• “ Back-end navigation path ” on page 275
• “ MP Blades navigation path ” on page 273
• “ Pools navigation path ” on page 278
• “ Snapshot Pool navigation path ” on page 282
• “ Replication Volumes navigation path ” on page 284
• “ LUSE navigation path ” on page 285
• “ Host Groups navigation path ” on page 287
• “ Ext-RG(s) navigation path ” on page 291
• “ Drive types navigation path ” on page 292
• “ Custom groups navigation path ” on page 293
MP Blades navigation path
IMPORTANT:
This section is applicable only for the P9000 disk arrays.
The MP Blades main category comprises the individual MP blades for a P9000 disk array. Each MP
blade is identified by the cluster # and the blade location, and further displays the list of processors.
Following is the component selection path: MP Blades > Individual MP Blade (ID, cluster #, blade
location) > Processors (component type) > Individual processor IDs.
• MP Blades > Individual MP Blade
• Individual MP Blade > Processors (component type) > Individual processor IDs
The number of components associated with an MP blade is displayed beside it. For example:
• MP Blade (2)
• Processors (4)
