The applicable metrics are displayed in the Available Metrics Choose Metric Category list. Select the
metrics at the component type or the individual component levels, or both to view the related
performance graphs in the Chart Work Area. For a description of these metrics, see “
The following table provides the default set of metric categories that are displayed in the Available
Metrics Choose Metric Category list for the XP and the P9000 disk arrays. The Yes and No under For
the XP disk arrays and For the P9000 disk arrays columns indicate whether the particular default
metric is applicable for that XP or P9000 disk array.
For P9000 disk arrays
For XP disk arrays
Most used default metric cat-
egory
Front-end category
Yes
Yes
Frontend IO Metrics
Front-end
Yes
Yes
Frontend IO Metrics
Port
No
Yes
Utilization Metrics
MP
No
Yes
Utilization Metrics
CHA
IMPORTANT:
•
At the Front-end main category level, the Maximum Port IO/s – Frontend and the Maximum Port
MB/s – Frontend metrics provide the respective maximum I/Os and MB/s of data throughput of
all the ports in the selected XP or the P9000 disk array. These values are the maximum of the last
collection interval. For example, if the port I/O collection interval is set to two minutes, the Max-
imum Port IO will be calculated as the maximum value over the two minute collection interval.
•
When you plot the performance data points for a port ID, the associated port type is also displayed
in the legend for the selected port ID (example: (53046, CL2A (Fibre (Target)), Total).
Related Topics
•
•
•
•
•
•
Replication Volumes navigation path
•
•
•
•
•
Cache navigation path
The Cache main category comprises of individual CLPR partitions for the selected XP or P9000 disk
array (Cache > Individual CLPRs). The following image is an example for an XP disk array and shows
the CLPRs under the XP disk array Cache.
