HP XP P9000 Performance Advisor Software User Manual
Page 209
For P9000 disk arrays
For XP disk arrays
Individual CHIP/CHA data
Yes
Yes
The average I/Os and throughput of data
in MB/s on all the ports in the selected
CHIP/CHA
Port Details
No
Yes
The individual MPs on the selected
CHIP/CHA
Yes (the port IDs are directly displayed
under the selected CHA.
Yes
The IDs of the associated ports on the
selected CHIP/CHA
Yes
Yes
The maximum and minimum I/Os on
individual ports
Yes
Yes
The maximum, minimum, and average
throughput of data in MB/s on individual
ports
Example:
The following image displays the CHA-1EU performance data for 53036, which belongs to the P9500
Disk Array type.
The individual performance data for CHA-1EU includes the following:
•
Summary:
• Fibre protocol is used
• Eight ports are associated with CHA-1EU
• Port Activity Avg shows average I/Os as 10409.17, which is an average of the overall average
I/Os on all the eight ports. It also displays the average MB/s as 81.33, which is the an average
of the overall average MB/s on all the eight ports.
•
Port Details:
• CL1A, CL5A, CL3A, and CL7A are the ports for CHA-1EU
• Maximum and minimum I/Os
• Maximum, minimum, and average throughput of data in MB/s
For example, the Max I/Os and Min I/Os for CL1A are 17290.00 and 5998.00
Related Topics
•
•
HP StorageWorks P9000 Performance Advisor Software User Guide
209
