Description Screen element
Failed or Active.
NOTE:
When Continuous access is configured as Sync or
Async and the selected volume type is SVOL, then
you might encounter the CA Link status as NA -
Not Applicable.
CA Link Status
Number of active continuous access paths from a
PVOL to SVOL.
NOTE:
When Continuous Access is configured as Sync
or Async and the selected volume type is SVOL,
then you might encounter the status of the number
of paths as NA - Not Applicable. No. of Paths
Fence level of target device (Pair volume). Displays
one of the following:
• ASYNC for asynchronous communications
• DATA, STATE, or NEVER for synchronous commu-
nications
• JNL for continuous access journal based transac-
tions
Fence Level
Journal ID of the journal group associated with the
P-VOL or S-VOL.
JNL-ID
CTG ID, which guarantees consistency in the sequence
of asynchronous data transfers for a remote copy
volume group.
CTG-ID
Host port assigned for the P-VOL. P-VOL Host Port
Host port assigned for the S-VOL. S-VOL Host Port
CLPR based on the associated volume type (P-VOL or
S-VOL) manages cache for the continuous access
transactions.
CLPR
MP blade based on the associated volume type (P-VOL
or S-VOL) processes requests for the continuous access
transactions.
MP Blade
RAID group to which volume type (P-VOL or S-VOL)
the LDEV belongs.
RG
RAID classification for the RAID group is determined
based on the associated volume type (P-VOL or S-VOL).
RAID Level
Viewing XP and P9000 disk array components 224
