D Appendix D
Array mapping
To correctly map the ACP and CHIP pairs, see the following tables for the respective array:
“XP128 (1 ACP Pair)” (page 385) lists ACP and CHIP pairs for disk array XP48/128.
NOTE: The cards are lettered A-M, omitting I.
Table 33 XP128 (1 ACP Pair)
Slot ID Pair ID Slot name
ACP B = 0; L = 4 ACP Pair 1 B, L
CHIP C = 0; G = 4 CHIP Pair 1 C, G
CHIP D = 1; J = 5 CHIP Pair 2 D, J
CHIP F = 2; K = 6 CHIP Pair 3 F, K
“XP128 (2 ACP Pairs)” (page 385) lists the ACP and CHIP pairs for disk array XP48/128.
NOTE: The cards are lettered A-M, omitting I.
Table 34 XP128 (2 ACP Pairs)
Slot ID Pair ID Slot name
ACP B = 0; L = 4 ACP Pair 1 B, L
ACP F = 1; K = 5 ACP Pair 2 F, K
CHIP C = 0; G = 4 CHIP Pair 1 C, G
CHIP D = 1; J = 5 CHIP Pair 2 D, J
“XP1024” (page 385) lists the ACP and CHIP pairs for XP1024.
Table 35 XP1024
Slot ID Pair ID Slot name
ACP B = 0; H = 4 ACP Pair 1 B, H
ACP C = 1; J = 5 ACP Pair 2 C, J
ACP D = 2; K = 6 ACP Pair 3 D, K
ACP E = 3; L = 7 ACP Pair 4 E, L
CHIP P = 0; V= 4 CHIP Pair 1 P, V
CHIP Q = 1; W= 5 CHIP Pair 2 Q, W
CHIP R = 2; X= 6 CHIP Pair 3 R, X
CHIP S = 3; Y= 7 CHIP Pair 4 S, Y
“XP12000” (page 386) lists the ACP and CHIP pairs for XP12000 type array.
