7.4 Motor data / characteristic curve parameters
BU 0750 GB-3311 Subject to technical amendments 87
7.4 Motor data / characteristic curve parameters
Parameter
Setting value / Description / Note
Parameter
set
Available with option
P200 Motor list P Always visible
0 ... 32
[ 0 ]
The factory settings for the motor data can be edited with this parameter. The factory setting in
parameters P201...P209 is a 4-pole DS standard motor with the nominal FI power setting.
By selecting one of the possible digits and pressing the ENTER key, all motor parameters
(P201…P209) are adjusted to the selected standard power. The basis for the motor data is a 4-
pole DS standard motor.
0 = No change to data
1 = No motor: In this setting, the FI operates without current control, slip compensation and
pre-magnetising time, and is therefore not recommended for motor applications. Possible
applications are induction furnaces or other applications with coils and transformers. The
following motor data is set here: 50.0Hz / 1500rpm / 15.0A / 400V / 0.00kW / cos

=0.90 /
Stern / R
S
0,01

/ I
LEER
6.5A
2 = 0.25kW
3 = 0.37kW
4 = 0.55kW
5 = 0.75kW
6 = 1.10kW
7 = 1.50kW
8 = 2.2kW
9 = 3.0kW
10 = 4.0kW
11 = 5.5kW
12 = 7.5kW
13 = 11kW
14 = 15kW
15 = 18.5kW
16 = 22kW
17 = 30kW
18 = 0.25hp
19 = 0.50hp
20 = 0.75hp
21 = 1.00hp
22 = 1.50hp
23 = 2.00hp
24 = 3.00hp
25 = 5.0hp
26 = 7.5hp
27 = 10hp
28 = 15hp
29 = 20hp
30 = 25hp
31 = 30hp
32 = 40hp
Note: As P200 returns to = 0 after the input confirmation, the control of the set motor can be
implemented via parameter P205.
P201 Nominal frequency P Always visible
20.0..00.3990.9 Hz
[

]
The motor nominal frequency determines the V/f break point at which the FI supplies the nominal
voltage (P204) at the output.
P202 Nominal speed P Always visible
300..0.24000 rpm
[

]
The nominal motor speed is important for the correct calculation and control of the motor slip and
the speed display (P001 = 1).
P203 Nominal current P Always visible
0.1..00.5400.0 A
[

]
The nominal motor current is a decisive parameter for the current vector control.
P204 Nominal voltage P Always visible
100..0.800 V
[

]
The >Nominal voltage< matches the mains voltage to the motor voltage. In combination with the
nominal frequency, this produces the voltage/frequency characteristic curve.
P205 Nominal power P Always visible
0.00... 315.00 kW
[

]
The motor nominal power controls the motor set via P200.
P206 cos 
P Always visible
0.50...0.90
[

]
The motor cos

is a decisive parameter for the current vector control.

These setting values depend on the selection in parameter P200.
