7.10 Parameter overview, User settings
BU 0750 GB-3311 Subject to technical amendments 127
Parameter
No.
Name
Factory
setting
Setting after commissioning
P 1 P 2 P 3 P 4
CONTROL PARAMETERS (7.5) Encoder option
P300 (P) Servo Mode [Off / On] 0
P301 Incremental encoder pulse number 6
P310 (P) Speed controller P [%] 100
P311 (P) Speed controller I [%/ms] 20
P312 (P) Torque current controller P [%] 200
P313 (P) Torque current controller I [%/ms] 125
P314 (P) Limit, torque current controller [V] 400
P315 (P) Field current controller P [%] 200
P316 (P) Field current controller I [%/ms] 125
P317 (P) Limit, field current controller [V] 400
P318 (P) Field weakening controller P [%] 150
P319 (P) Field weakening controller I [%/ms] 20
P320 (P) Field weakening limit [%] 100
P321 (P) Increase speed control I 0
P325 Encoder function 0
P326 Encoder conversion 1.00
P327 Slip error limit 0
P330 Digital input 13 0
CONTROL TERMINALS (7.6)
P400 Function Analog input 1 1
P401 Analog On mode 1 0
P402 Adjustment 1: 0% [V] 0.0
P403 Adjustment 1: 100% [V] 10.0
P404 Filter analog input 1 [ms] 100
P405 Function Analog input 2 0
P406 Analog On mode 2 0
P407 Adjustment 2: 0% [V] 0.0
P408 Adjustment 2: 100% [V] 10.0
P409 Filter analog input 2 [ms] 100
P410 (P) Min. freq. aux. setpoint [Hz] 0.0
P411 (P) Max. freq. aux. setpoint [Hz] 50.0
P412 (P) PID process controller setpoint [V] 5.0
P413 (P) P-component PID control [%] 10.0
P414 (P) I-component PID control [%/ms] 1.0
P415 (P) D-component PID control [%ms] 1.0
P416 (P) Ramp time PI setpoint. [s] 2.0
P417 (P) Analog output offset 1 [V] 0.0
P418 (P) Function analog output 1 0
P419 (P) Standardisation analog output 1 [%] 100
P420 Function of digital input 1 0 or 1
P421 Function of digital input 2 0 or 2
P422 Function of digital input 3 8
P423 Function of digital input 4 4
P424 Function of digital input 5 0
P425 Function of digital input 6 0
